Coffee Maker Thermostat Temperature Controller

Coffee Maker Thermostat Temperature Controller thumbnail-1
Coffee Maker Thermostat Temperature Controller photo-1
US$ 0.2 - 0.8 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Brand Name:
HW, LC
Model Number:
3A-CF2
Contact Supplier Request Quote Chat Now
Honest-well Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HW, LC
Model Number 3A-CF2

10A/15A 110V/220V Coffee Maker Thermostat



Overview:

(1) CONTACT TYPE : Contact Opens When Temperature Rises To Set Point (Normally Closed)

(2) CAP TYPE : C Cap

(3) TERMINAL ORIENTATION : Horizontal

(4) TERMINAL SIZE: Amp#250 TAB ( 6.35 mm x 0.8t mm )

(5) Housing Height: 9.6mm



Coffee Maker Thermostat Temperature Controller



Specification:

Electrical Rating 16A/250V AC 15A/125V AC 10A/250V AC
Operation Temp 0℃~180(VDE); 50℃~205℃(UL/CUL)
Differential 10K~30K
Calibration Method 1℃/min. Air circulation furnace
Temp. Tolerance ±3K / ±5K
Heat Durability 180℃*2Hr MAX.
Circuit Resistance 50 mΩ MAX.
Insulation Resistance 100MΩ min. at DC 500V
Dielectric Strength

AC1000V for One Minute or

AC 1800V for One Second(Leak current:0.5mA)
Operation life

100,000 Cycles(15A 125V AC / 10A 250V AC);

10,000 Cycles(16A 250V AC)
