Help CenterRA(R19A) Series Rocker Switch
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
HW
Model Number:
R19A
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Taiwan, China
Brand Name
HW
Model Number
R19A
Max. Current
15A
Max. Voltage
250V
Mechanical Life
30,000
RA(R19A) Series Rocker Switch
Spec:
| Electrical Rating |
2A 125V AC/250V AC(UL,VDE) 6A 250V AC(standard)(UL,VDE) 15A 125V AC & 8A 250V AC(UL) |
| Mechanical life | Over 30000 cycles |
| Electrical life | Over 10000 cycles |
| Contact resistance | <20mΩ |
| Insulation resistance | >1000MΩ |
| High voltage resistance | >1500VAC 1 min. |
| Ambient temperature | Terminal side -20 to +85°C |
| Actuating side | - 20 to +55°C |
| Atmospheric humidity | Max.85% |
| Actuating force | 3 to 6N(depends on different switch function) |
| Flammability | UL94V-2 & UL94V-0 |
| Storage temperature | -30 to +80°C Max |
| Temperature rise at the terminal | Max 30°C (UL1054) |
| Solder ability of terminal | Max 350°C 3s |
Material:
| Housing | Nylon 66 |
| Rocker | PC & PA66 |
| Contact | Silver Alloy |
| Terminal | Brass Silver Plated |
| Lamp | Neon Lamp, Tungsten Lamp |
| Spring | SWP, SUS |
| Movable Arm | Brass Silver Plated |
