Help Center12A Illuminated Neon Lamp Rocker Switch
US$ 0.3 - 1
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Brand Name:
LC
Model Number:
SS21
Max. Current:
12A
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
LC
Model Number
SS21
Max. Current
12A
Max. Voltage
250V
Mechanical Life
30000 times
12A Illuminated Neon Lamp Rocker Switch
Specification:
| Electrical Rating | 10A 125/250VAC(UL) |
| 12(4)A 250VAC(VDE) | |
| Mechanical life | Over 30000 cycles |
| Electrical life | Over 10000 cycles |
| Contact resistance | <20mΩ |
| Insulation resistance | >1000MΩ |
| High voltage resistance | >1500V 1 min. |
| Ambient temperature | Terminal side -20 to +85°C |
| Actuating side | -20 to +55°C |
| Storage temperature | -30 to +80°C Max |
| Atmospheric humidity | Max.85% |
| Actuating force | 4 to 8N |
| Flammability | 94V-0 |
| Temperature rise at the terminal | Max 30°C (UL1054) |
| Solder ability of terminal | Max 350°C,3s |
Materials:
| Housing | Nylon 66 UL94V-0 |
| Rocker | Nylon 66 UL94V-0 |
| Contacts | Copper alloy silver plated |
| Terminal | Copper alloy silver plated |
| Spring | Stainless steel wire |
| Movable Arm | Copper alloy |
| Roller | Brass alloy |
