Help CenterSub-miniature 3A Toggle Switch
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
HW
Model Number:
2M
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Taiwan, China
Brand Name
HW
Model Number
2M
Mechanical Life
30,000
Sub-miniature 3A Toggle Switch
Specification:
| Mechanical Life | 30,000 make-and-break cycles |
| Contact Resistance | 20mΩ max. inital @ 2-4VDC 100mA for both silver and gold plated contacts. |
| Insulation Resistance | 1,000 MΩ min |
| Dielectric Strength | 1,000 V RMS min. @ sea level |
| Operating Temperature | -30°C ~ 85°C |
MATERIALS
- CASE: Diallyl phthalate (DAP) (UL94v-0)
- Actuator: Brass chrome Plated
- Busing: Brass nickel plated.
- Housing: Stainless Steel
- Switch Support: Brass Tin plated
- Terminal/Contact: Brass with silver or gold plated.
