Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
HW
Model Number:
LC83
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SK22D13 2P2T Horizontal Type Slide SwitchUS$ 0.05 - 0.1MOQ: 2000 Pieces -
SS24 Series Rocker SwitchNegotiableMOQ: 1000 Pieces
-
MLS Series Pushbutton SwitchNegotiableMOQ: 1000 Pieces
-
PS001 Series Pushbutton SwitchNegotiableMOQ: 1000 Pieces
-
SS22F39 2P2T Vertical Type Slide SwitchUS$ 0.05 - 0.1MOQ: 2000 Pieces
Place of Origin
Taiwan, China
Brand Name
HW
Model Number
LC83
Size
13 X 19 mm
Mechanical Life
30,000
LC83 Series Pushbutton Switch
Specification:
| Electrical Rating | 15A 250VAC/125VAC (UL) 10(4)A 250VAC (VDE) |
| Mechanical Life | Over 30,000 cycles |
| Electrical Life | Over 10,000 cycles |
| Contact Resistance | < 20mΩ |
| Insulation Resistance | >1,000MΩ |
| High Voltage Resistance | >1,500MΩ, 1 min |
| Ambient Temperature | Terminal Side: -20°C ~ 85°C Actuating Side: -20°C ~ 55°C |
| Storage Temperature | -30°C ~ 80°C |
| Atmospheric Humidity | Max 85% |
| Actuating Force | 3~6N (Depends on different switch function) |
| Flammability | 94V-2 |
| Temperature Rise at Terminal | Max 30°C (UL1054) |
| Solder Ability of Terminal | Max 350°C, 3s |
Material:
- Housing: PA66
- Rocker: PC
- Contacts: Silver Alloy
- Terminal: Copper Silver Plated
- Spring: SUS
- Movable Arm: Copper Silver Plated
- Lamp: Neon Lamp, Tungsten Lamp
- Bracket: PA66
