Challenge Medalist 870 Air Feed Paper Folder w/ stand
Automatic document folding machine
Can fold up to 30000 Sheets/Hour
Creates 6 different fold types: letter, z-fold, single, double parallel, baronial and French
For use with 4" x 6" up to 14" x 20" paper, 9 - 65 lbs
Air feed
Product Info
Description
The Challenge Medalist 870 Air Feed Paper Folding Machine feeds effortlessly at up to 30,000 sheets per hour. A flip-up swing deflector lets stock bypass the fold plate and the feed table swings up for easy access to the lower fold plate. Perfing and scoring shafts are very accessible, for fast changes. The control panel has a built-in total counter and is accessible from either side. The Medalist folder handles stock from 4" x 6" to 14" x 20", including coated paper. The Medalist is built to last, and requires minimal maintenance.
Features
Up to 30,000 8-1/2" x 11" sheets per hour
Large folder up-down plate configuration
Flip-up swing deflectors allow set-up changes without fully removing fold plates
Easy access heavy-duty slitter shafts
A unique jam detector system stops the feeder before problems become significant
Precision roller calipers hold roller gap based on paper thickness during folding
Noise hoods
The control panel includes a counter and reset button, and is accessible from either side
Features
|
Freight shipping |
Yes |
Feed Method |
Air Feed |
Standard Fold Types |
Single, Letter, Double Parallel and More |
Max Folding Speed |
30000 Sheets/Hour |
Min Paper Size |
4" x 6" |
Max Paper Size |
14" x 20" |
Foldable Paper Weights |
9 lbs - 65 lbs lbs |
Foldable Types of Paper |
Plain and Glossy |
Digital Display |
Yes |
Sheet Counter |
Yes |
Paper Jam Detection |
Yes |
Scoring Capability |
Yes |
Slitting Capability |
Yes |
Perforating Capability |
Yes |
Variable Speed |
Yes |
Volts |
120 V |
Hertz |
60 Hz |
UL Listed |
Yes |
Dimensions (L x W x H) |
61 1/2" x 25" x 26" |
Shipping Weight |
475 lbs |
Features
Up to 30,000 8-1/2" x 11" sheets per hour
Large folder up-down plate configuration
Flip-up swing deflectors allow set-up changes without fully removing fold plates
Easy access heavy-duty slitter shafts
A unique jam detector system stops the feeder before problems become significant
Precision roller calipers hold roller gap based on paper thickness during folding
Noise hoods
The control panel includes a counter and reset button, and is accessible from either side
D.C. drive
1-1/2" Diameter combination rollers
Includes a stand, thin scoring blade, rubber scoring tire, 41-teeth perf blade, perf stripper, perf block, blade holder, 1/8" allen wrench, manual, (2) scoring blocks, (2) paper deflectors, (2) 5/32" allen wrenches
