Specifications
1.EMH23-25 pneumatic metal forging machine2.good rigidness
3.PLC
4.pneumatic control
5.ISO9001
EMH23-25 pneumatic metal forging machine
1. The lathe features good rigidness, stable precision, slider with mechanical overload protection device, and it is safe, reliable and has a long service life.
2. The machine adopts combined pneumatic friction clutch-brake, and it features compact structure, smooth transmission, flexible action, convenient operation and low noise.
3. By means of electrical devices and pneumatic control, the machine can make jog, single, and continuous punching, as well as emergent brake.
4. All these presses adopt PLC centralized control. There is a socket for the installation of photoelectric protection device in the electrical control system, which meets the safety requirements of users.
5. The lathe features high efficiency of automatic production. With high performance and reasonable price, EMH23-25 pneumatic metal forging machine is an upgrade product for EMM23.
Standard export packing of EMH23-25 pneumatic metal forging machine .
Technical date of EMH23-25 pneumatic metal forging machine.
| Technical Data | Unit | EMH23-16 | EMH23-25 | EMH23-35 | EMH23-40 | EMH23-63 | EMH23-80 | EMH23-100 | |
| Nominal Capacity (Pe) | KN | 160 | 250 | 350 | 400 | 630 | 800 | 1000 | |
| Nominal Stoke(Sp) | mm | 2 | 2.5 | 3.5 | 6 | 7 | 7 | 7 | |
| Nominal Stoke(S) | mm | 55 | 65 | 80 | 90 | 110 | 120 | 140 | |
| Slide Strokes Per Minute(n) | times/ min | 125 | 80 | 60 | 50 | 50 | 38 | 38 | |
| Maximum Die Set Height(H2) | mm | 220 | 270 | 290 | 320 | 390 | 440 | 480 | |
| Die Height Adjustment(t) | mm | 45 | 55 | 60 | 65 | 80 | 90 | 100 | |
| Throat Depth(C1) | mm | 160 | 200 | 220 | 250 | 310 | 350 | 380 | |
| Distance Between Uprights(d1) | mm | 220 | 270 | 280 | 340 | 420 | 450 | 560 | |
| Slide Bottom Size | L×R(a) | mm | 200 | 250 | 250 | 300 | 400 | 450 | 540 |
| F×B(b) | mm | 180 | 220 | 220 | 260 | 360 | 360 | 480 | |
| Stem hole Size | Dia(d) | mm | 40 | 40 | 40 | 50 | 50 | 60 | 60 |
| Depth(l) | mm | 60 | 60 | 60 | 70 | 70 | 75 | 75 | |
| Bolster Size | L×R(C) | mm | 450 | 560 | 610 | 700 | 860 | 950 | 1080 |
| F×B(D) | mm | 300 | 370 | 400 | 460 | 570 | 650 | 710 | |
| Bolster Thickness(H3) | mm | 40 | 50 | 60 | 65 | 80 | 100 | 120 | |
| Max. Angle Of Inclination(2) | ° | 35 | 30 | 30 | 30 | 20 | 20 | 15 | |
| Bolster Surface Height(H1) | mm | 750 | 800 | 815 | 850 | 850 | 850 | 850 | |
| Overall Dimensions | F×B(A) | mm | 1200 | 1345 | 1462 | 1750 | 1930 | 2060 | 2404 |
| L×R(B) | mm | 1050 | 1170 | 1195 | 1376 | 1560 | 1915 | 2180 | |
| H | mm | 1960 | 2132 | 2215 | 2488 | 2740 | 3290 | 3625 | |
| Distance Between Foundation Bolts | F×B(a’) | mm | 780 | 920 | 1020 | 1060 | 1300 | 1360 | 1550 |
| L×R(b’) | mm | 450 | 600 | 650 | 750 | 920 | 1010 | 1130 | |
| Motor Power | KW | 1.5 | 3 | 4 | 5.5 | 7.5 | 7.5 | 11 | |
| Weight(Approximate) | Kg | 1185 | 2050 | 2530 | 3590 | 5440 | 7860 | 11250 | |
Presale Service
We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.
Service during the Sale
1. We are manned with professional salesmen and technicians to provide the information, technical support and the optimal solutions with high cost performance.
2. Based on the specific requirements of customers and the lead time, we will formulate a rigorous operation process. Through the close cooperation of Commodity Department, Sales Department, Technical Department and the Ocean Shipping Department, we are devoted to timely supplying customers with superior machines.
3. Generally, certain quantity of quick-wear parts will be delivered with the goods. The delivery deadline depends on the specific order, which is usually within 1 to 3 months.
After-Sale Service
1. One year warranty is provided.
2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the
warranty, we only charge for the basic costs of parts.
3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
EMM is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team members includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
1.What's the feature of the EMH23-25 pneumatic metal forging machine?
The lathe features high efficiency of automatic production. With high performance and reasonable price, EMH23 is an upgrade product for EMM23.
