EMH23-16 plate steel punching machine

Specifications

1.EMH23-16 plate steel punching machine
2.good rigidness
3.PLC
4.pneumatic control
5.ISO9001

 EMH23-16 plate steel punching machine





1. The lathe features good rigidness, stable precision, slider with mechanical overload protection device, and it is safe, reliable and has a long service life.



2. The machine adopts combined pneumatic friction clutch-brake, and it features compact structure, smooth transmission, flexible action, convenient operation and low noise.



3. By means of electrical devices and pneumatic control, the machine can make jog, single, and continuous punching, as well as emergent brake.



4. All these presses adopt PLC centralized control. There is a socket for the installation of photoelectric protection device in the electrical control system, which meets the safety requirements of users.



5. The lathe features high efficiency of automatic production. With high performance and reasonable price, EMH23-16 plate steel punching machine is an upgrade product for EMM23.







Technical date of EMH23-16 plate steel punching machine.



Technical Data		Unit	EMH23-16	EMH23-25	EMH23-35	EMH23-40	EMH23-63	EMH23-80	EMH23-100
Nominal Capacity (Pe)		KN	160	250	350	400	630	800	1000
Nominal Stoke(Sp)		mm	2	2.5	3.5	6	7	7	7
Nominal Stoke(S)		mm	55	65	80	90	110	120	140
Slide Strokes Per Minute(n)		times/ min	125	80	60	50	50	38	38
Maximum Die Set Height(H2)		mm	220	270	290	320	390	440	480
Die Height Adjustment(t)		mm	45	55	60	65	80	90	100
Throat Depth(C1)		mm	160	200	220	250	310	350	380
Distance Between Uprights(d1)		mm	220	270	280	340	420	450	560
Slide Bottom Size	L×R(a)	mm	200	250	250	300	400	450	540
	F×B(b)	mm	180	220	220	260	360	360	480
Stem hole Size	Dia(d)	mm	40	40	40	50	50	60	60
	Depth(l)	mm	60	60	60	70	70	75	75
Bolster Size	L×R(C)	mm	450	560	610	700	860	950	1080
	F×B(D)	mm	300	370	400	460	570	650	710
Bolster Thickness(H3)		mm	40	50	60	65	80	100	120
Max. Angle Of Inclination(2)		°	35	30	30	30	20	20	15
Bolster Surface Height(H1)		mm	750	800	815	850	850	850	850
Overall Dimensions	F×B(A)	mm	1200	1345	1462	1750	1930	2060	2404
	L×R(B)	mm	1050	1170	1195	1376	1560	1915	2180
	H	mm	1960	2132	2215	2488	2740	3290	3625
Distance Between Foundation Bolts	F×B(a’)	mm	780	920	1020	1060	1300	1360	1550
	L×R(b’)	mm	450	600	650	750	920	1010	1130
Motor Power		KW	1.5	3	4	5.5	7.5	7.5	11
Weight(Approximate)		Kg	1185	2050	2530	3590	5440	7860	11250
