Specifications
EMM106-1 machine for thermoplastic elastomer1.high-tech model
2 three-component
3.imported parts
4.PU system
EMM106-1 machine for thermoplastic elastomer
EMM106-1 machine for thermoplastic elastomer a new kind compact type machine, develop on the base of EMM090 series, has reached to the world level. EMM106 suit for precision casting two component MDI systematic and PU elastomer system.
EMM106-1 machine for thermoplastic elastomer
Profuct specification
Applicable Viscosity:
A (POLY ): ~4000mpa.s (45℃-130℃)
B (MDI ,1,4-Butanediol,E300): ~4000mpa.s (45℃-130℃)
Main parameter:
3.1 The max. capacity: A/250L B /60L
The safe capacity: A/200L B /50L
3.2 Output ( 100:10) : 1-3L/min
matching range 1:1-5:1
machine head with 2 sets of additives or color injection system ( optional)
3.3 Vacuum system used for material vacuum supply and material add
3.4 Each material tank has heating system , which can get 130 ℃
3.5 PLC control system has digital terminal colour touch screen, can save up to six formula.
EMM106-1 machine for thermoplastic elastomer
| A | B | Color 1 | Color 1 |
Quantity | 1 | 1 | 2 | 1 |
Metering pump type | GMB01D/12cc /(Barmag) | GMA21D/6cc /(Barmag) | GMD31D/0.3CC /(Barmag) | JRG0.15/0.15cc /(China) |
Shift motor power | 1.5 kw | 0.75 kw | 0.37kw | 0.37kw |
Speed(Rpm) | 40-200 | 40-200 | 40-200 | 40-200 |
pump sealing lubricating | DOP | DOP | DOP | DOP |
EMM106-1 machine for thermoplastic elastomer
Packaging Detail : standard export packing
Shipping: FOB shanghai by sea
EMMis a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
1 year quality guaranty for the main spare parts, not include quick-wears parts, like blade, punch, die and so on.
During the guarantee period, we will provide spare parts without any charge in case of quality discrepancy caused by us.
If the malfunctions are caused by customer's incorrect operations, we will offer the spare parts at cost price.
Anyway, our company promises to supply the customer cost price of spare parts and provide long-term technical guide beyond the guarantee.
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
EMM106-1 machine for thermoplastic elastomer
