EMM brand EMM102 elastomer machine
- 50 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Lightweight thermal insulation house prefabricated wall panel price
- Mgo Sound insulation and heat preservation concrete hollow lightweight partition wall panels
- lightweight partition wall panel
- building material Mgo precast wall panels
- Mgo lightweight concrete foam wall panels Quality Choice
- Supply perforated/acoustic/sound-absorb wall panel mgo board/fireproof mgo board/magnesium oxide board
Product Details
Condition: | New | Product Type: | Foam Net | Brand Name: | EMM |
Model Number: | EMM102-2 | Voltage: | 380V/220V | Power(W): | 27000 |
Dimension(L*W*H): | 2800x1380x2000 | Weight: | 1.5Ton | Certification: | Other, ISO9001 |
Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
EMM brand EMM102 elastomer casting machine
1. Introduction
EMM102 series elastomer casting machine is our company tracking international high-end technology products, with the polyurethane industry application independent innovation and development of a high technology products. The Main parts are imported from foreign countries, technical and safety performance of the equipment has reached the advanced level of the same product of the same period abroad.
EMM102 series elastomer casting machine has two to five components, flow rate from 0.2 kg/minutes to 120 kg/minutes. The feed store from 20 to 1000 L.
EMM102-2 two components elastomer casting machine, using one prepolymer (A), one MOCA material cans, two measurement units by frequency conversion governor control respectively metering pump output flow, thereby change different mixing index. Especially for the TDI or MDI system of polyurethane elastomer products.
2. Main parameters and descriptions for the equipment
2.1 Type: EMM102-2
2.2 Suitable: polyurethane elastomer products
2.3 Suitable material viscosity (80℃--160℃):
Prepolymer: ~4000mpa.s
MOCA:10~1000mPas
2.3 Pouring output: 2-7kg/min (mixing-ratio100:14),
with mixing-ratio range adjustable: 100:6-100:20
2.5 Casting program time: 0.5 ~ 99.99 s (accurate to 0.01 s)
2.6 Inject the quantity of the procedure:
Manual / automatic inject: 9
2.7 Metering unit: For the measurement of components, measurement accuracy of ≤ 0.5%.
Used to component measurement, include bracket, frequency conversion speed reduction gear motor, couplings, metering pump, speed sensor, electronic pressure transmitter.
2.8 Working pressure limit and control system
The prepolymer and MOCA components work pressure control between in 0 ~ 4 Mpa. If working pressure beyond the scope of the set, the equipment to be automatic stop injecting, alarm and show "work pressure is not normal" fault information.
Components of the metering pump minimum preloading protect prepolymers pump set for 0.25 MPa, MOCA pump set to 0.15 MPa.
item | description | quantity | |
1 | Machine frame | China | 1 set |
2 | A(Prepolymer) metering unit | Metering pump:Hafei Motor:Taiwan | 1 sets |
3 | B(MOCA ) metering unit | Metering pump:Hafei Motor:Taiwan | 1 set |
4 | C(Color)metering unit(optional) | Metering pump:Hafei Motor:Taiwan | 1 set |
5 | Pressure limit and control unit | China | 3sets |
6 | Flow controls and filling unit | Taiwan-owned enterprise | 2 set |
7 | Prepolymer nets type filter | China ST50-2A (300μm) | 1 sets |
8 | MOCA nets type filter | China SG25-2A(200μm) | 1 set |
EMM brand EMM102 elastomer casting machine: Standard export package
Presale Service
We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.
Service during the Sale
1. We are manned with professional salesmen and technicians to provide the information, technical support and the optimal solutions with high cost performance.
2. Based on the specific requirements of customers and the lead time, we will formulate a rigorous operation process. Through the close cooperation of Commodity Department, Sales Department, Technical Department and the Ocean Shipping Department, we are devoted to timely supplying customers with superior machines.
3. Generally, certain quantity of quick-wear parts will be delivered with the goods. The delivery deadline depends on the specific order, which is usually within 1 to 3 months.
After-Sale Service
1. One year warranty is provided.
2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the
warranty, we only charge for the basic costs of parts.
3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
EMM's is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM's team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
1. What does the EMM brand EMM102 elastomer casting machinecan produce ?
Re: Can produce rollers , industry pieces.
