EMMCHINA S322 horizontal used pipe threading machine
S322 pipe threading lathe is mainly used to process inside and outside the pipe thread as well as metric, inch thread. At the same time can also be used as a general ordinary lathe, for shaft, disk cylindrical parts, in the hole and face processing.
Machine is equipped with taper gear, can be used for processing parts with taper.
| Main features | Processed pipe thread diameter range | 50-220 mm |
| Max.swing over bed | 630mm 800mm | |
| Max.swing over carriage | 350mm,550mm | |
| piece length | 1500mm,3000mm | |
| Max taper | 1:04 | |
| Max stroke of taper bar | 500mm | |
| Windth of bed | 490mm | |
| Main Drive System | Spindle bore | 225mm |
| Steps of spindle speed | 12 | |
| Range of spindle speed | 24-300 r/min | |
| Steps of reverse spindle speed | 6 | |
| Range of reverse spindle speed | 38-384 r/min | |
| Feed system | Longitudinal feed kinds and scope | 26 kinds/0.07-1.33mm |
| Transverse feeding kinds and scope | 22 kinds/0.02-0.45mm | |
| Thread metric No/Range | 24 kinds/1-14mm | |
| Thread whitworth No/Range | 40 kinds/2-28 teeth/inch | |
| Pinth of screw | 1/2 inch | |
| Bed saddle rapid traverse | 4000mm/min | |
| Bed saddle longitudinal max. stroke | 1310,2810mm | |
| tool post | bottom slide maximum transverse stroke | 390,490mm |
| Max.travel of tool post | 200mm | |
| Swing angle of tool post | ±60º | |
| bottom slide plate movement | 0.05mm/case | |
| tool post dial movement | 0.05mm/case | |
| Tailstock | Dia of sleeve | 100mm |
| Taper of sleeve | Morse 5 | |
| Sleeve stroke | 205mm | |
| Lateral movement range | ±15mm | |
| Power system | Main motor | Y160M-6 7.5KW 970r/min |
| Rapid feed motor power | ACH-90 0.3KW 1450r/min | |
| Cooling system | Cooling pumps | CB-22 0.125KW 2800r/min |
| Machine | Overall dimensions(L*W*H) | (3657,5157)×1449×1393mm |
| Weight | 4440,5290kg |
EMMCHINA S322 horizontal used pipe threading machine
Provide Pre-sales Consultant & On-purchase service 8 hr × 6 days per week
1. Reply within 24 hours
2. Provide relevant product information
3. Answer question of customer's requirement
4. Give technical suggestion
Provide After-sales service 24hr × 7days per week
1. Test the machine before shipment
2. Provide technical guidance relate to use the machine
3. Supply one-year warranty period for the machine
4. Provide the spare parts at cost price after warranty period
5. Collect the feedback for the machine working
6. Provide long-term technical assistance.
EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
EMMCHINA S322 horizontal used pipe threading machine
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
EMMCHINA S322 horizontal used pipe threading machine
