EMMCHINA SK338 Horizontal Cnc Pipe Threading Machine

EMMCHINA SK338 Horizontal Cnc Pipe Threading Machine photo-1
EMMCHINA SK338 Horizontal Cnc Pipe Threading Machine photo-2
EMMCHINA SK338 Horizontal Cnc Pipe Threading Machine photo-3
EMMCHINA SK338 Horizontal Cnc Pipe Threading Machine photo-4
EMMCHINA SK338 Horizontal Cnc Pipe Threading Machine photo-5
EMMCHINA SK338 Horizontal Cnc Pipe Threading Machine photo-6
US$ 42,998 - 75,998 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Horizontal
CNC or Not Normal
Automatic Grade Manual
Max. Swing Diameter 800mm
Place of Origin Jiangsu, China
Brand Name EMM
Model Number SK338
Voltage Optional
Power(W) 22kw
Dimension(L*W*H) 5000X2200X520mm
Weight 11050kgs
Certification ISO9001
After-sales Service Provided Engineers available to service machinery overseas

EMMCHINA SK338 horizontal cnc pipe threading machine



EMMCHINA SK338 horizontal cnc pipe threading machine



Product Description



EMMCHINA SK338 horizontal cnc pipe threading machine is mainly used to process inside and outside the pipe thread as well as metric, inch thread. At the same time can also be used as a general ordinary lathe, for shaft, disk cylindrical parts, in the hole and face processing.

Machine is equipped with taper gear, can be used for processing parts with taper.



Main featuresProcessed pipe thread diameter range190-320 mm
Max.swing over bed1000mm
Max. swing over tool610mm
piece length1700mm
Windth of bed755mm
Main Drive SystemSpindle bore330mm
Steps of spindle speed9
Range of spindle speed6-205r/min
Feed systemFeeding and thread pitch range0.0001-40mm
tool post transverse travel500mm
Bed saddle longitudinal max. stroke1450
tool postmain shaft center to the vertical distance tool installation datum48mm
Cutting tools section size45x45mm
TailstockDia of sleeve140mm
Taper of sleeveMorse 6
Sleeve stroke300 mm
Lateral movement range±25mm
Power systemMain motorY180L-4-B3  22KW  1460r/min
gear pumpCB-B10  2.5MPa   1450 r/min
Main motor belt5-C2000
Gear pump belt1-A1660
Cooling systemCooling pumpsJCB-45  0.15KW  22L/min
Machine Overall dimensions(L*W*H)5000×2200×1520mm
Weight11500kg
