Specifications
W11-8x3000 mechanical 3 roller plate bending machine1.NC control
2.Hydraulic system
W11-8x3000 mechanical 3 roller plate bending machine
The Function and Application Scope of the Machinery
This is three-roller asymmetric rolling equipment. It is mainly used in the process of cold working in which the sheets within the thickness of ( 4 )mm can be bent into different diameter cylindrical tubes. It is widely used in decoration,construction industry etc.
W11-8x3000,the technical data as following :
Max thickness : 8mm
Max width : 3000mm
Yielding limit if sheet metal : 245Mpa
Diameter of top shaft: 250mm
Diameter of bottom shaft: 220mm
Central distance between bottom shafts: 320mm
Min diameter: 650mm
Motor power: 11kw
Weight: 5800 kg
