W11-6*3000 Mechanical 3-roller Rolling Machine/bending Machine

W11-6*3000 Mechanical 3-roller Rolling Machine/bending Machine thumbnail-1
W11-6*3000 Mechanical 3-roller Rolling Machine/bending Machine photo-1
US$ 8,000 - 15,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
EMM
Contact Supplier Request Quote Chat Now
Extreme Machinery Manufacture Co., Ltd. (Jingjiang)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name EMM
Model Number W11-6*3000
Machine Type Other, plate rolling machine
Raw Material Sheet / Plate Rolling
Material / Metal Processed Carbon Steel
Power Other, mechanical
Automation Other, NC
Extra Services End Forming
Certification ISO 9001:2000
After-sales Service Provided Engineers available to service machinery overseas

Specifications

W11-6*3000 mechanical 3-roller rolling machine/bending machine
1.NC control
2.Pre-bending functions
3.Hydraulic system

  W11-6*3000 mechanical 3-roller rolling machine/bending machine


1 .Introduction

The machine is a kind of three-roller machine with liquid pressure for all-purposes. It can shape steel board into cylinder, U model etc.

The upper roller may move vertically or horizontally.

Pre-bend of steel board performs with movement of upper roller based on no symmetry of location. Round mode of steel performs by two down rollers with slowdown of running from electric machine

The down roller fix the height, so material can easily enter the machine and workers operate machine expediently.



2 .Main technical parameter of the equipment





W11-6x3000, the technical data as following :

Max thickness :                                      6mm

Max width :                                           3000mm

Yielding limit if sheet metal :                    245Mpa

Min. bending diameter:                           600mm

Diameter of up roller:                              240mm

Diameter of bottom roller:                       180mm

Central distance between bottom rollers:             300mm

Rolling speed:                                 about 4m/min

Motor power:                                 7.5kw



 W11-6*3000 mechanical 3-roller rolling machine/bending machine
