Specifications
W11S-20*3200 plate rolling machine price1.NC control
2.Pre-bending functions
3.Hydraulic system
W11S-20*3200 steel plate rolling machine
1 .Introduction
The machine is a kind of three-roller machine with liquid pressure for all-purposes. It can shape steel board into cylinder, U model etc.
The upper roller may move vertically or horizontally.
Pre-bend of steel board performs with movement of upper roller based on no symmetry of location. Round mode of steel performs by two down rollers with slowdown of running from electric machine
The down roller fix the height, so material can easily enter the machine and workers operate machine expediently.
2 .Main technical parameter of the equipment
Part number |
upper roller movement for all-purposes |
Add pressure |
190 Tons |
Rolling capacity |
245Mpa |
Max bending length |
3200 mm |
Roller working length |
3300 mm |
Axletree |
wafangdian Axletree |
Roller material |
42 CrMo |
Diameter of upper roller |
380 mm |
Diameter of down roller |
220 mm |
Center distance |
360 mm |
Speed of roll |
About 4 m/min |
Full load condition End line length |
≤(3-2.5)times plate thickness |
Oil cylinder driving speed |
120mm/rmin |
Quantity of supporting rollers |
4 |
Group quantity of supporting rollers |
1 |
Power of key electric machine |
22 KW |
Power of electric machine with liquid pressure |
7.5 KW |
Power of removable electronic machine |
4 KW |
