Type |
800×800 |
1000×1000 |
1200×1200 |
1500×1500 |
Total press(MN) |
1.60 |
2.00 |
2.50 |
3.15 |
Plate size (mm) |
800×800 |
1000×1000 |
1200×1200 |
1500×1500 |
Plate gap (mm) |
300 |
300 |
300 |
300 |
Working layer number |
1 |
1 |
1 |
1 |
Piston stroke (mm) |
250 |
250 |
250 |
250(500) |
Unite area pressure of hot plate(Mpa) |
2.5 |
2.0 |
1.8 |
1.5 |
Motor power(Kw) |
3 |
5.5 |
8.0 |
8.0 |
|
(L×W×H)(mm) Overall dimension |
900×1600×2500 |
1100×1900×3600 |
1300×2100×40000 |
1600×2450×4200 |
Weight(Kg) |
4000 |
5800 |
6800 |
8000 |
Close mould speed (mm/s) |
≥6 |
≥6 |
≥6 |
≥6 |
Open mould speed (mm/s) |
≥4 |
≥4 |
≥4 |
≥4 |
. Frame type, rubber platen vulcanize machine is different from the column type, it is allowed to install larger diameter hydraulic cylinder, reducing the quantity of cylinders, with simple structure, and little maintain work. The frame can bear more stress and it has competitive price, nice surface, easy to operate.
Frame Type Plate Vulcanizing is used for pressing rubber products and thermosetting plastic products, also and is used for seals,project rubber and rubber plate etc. This series of products have high press in unit area , so that we can ensure the quality .Machine can be equipped with model pulling and pushing device to reduce work strength based on product requirements .Hand control ,electrical control and PLC control is optional.
