Solar Energy System PV Charge Controller 96V-30A/50A/100A/200A
- Ningbo or Shanghai or Shengzhen
- Money Gram Credit Card PayPal
You May Like
-
20kw off Grid Solar System BZC96V-200A PWM Solar Charge Controller
-
10kw off Grid Sine Wave Solar System120V-80A PWM Solar Charge Controller
-
Large LCD Display 120V-80A PWM Solar Charge Controller
-
96V-100A Electronic and Electrical Equipment PWM Solar Charge Controller
-
480V Rated Voltage PWM Solar Controller Application Solar Inverter
-
Top Quality PWM Solar Panel Charge Controller
Product Details
| Place of Origin | Zhejiang, China | Brand Name | BANGZHAO OR OEM | |
| Model Number | BZC-96V-30A or 50A or 100A or 200A | Specification | Normal | |
| Application | Industrial | Output Voltage (V) | 96V | |
| Load Power (W) | 3kw to 20kw | Solar Power (W) | 3kw to 20kw | |
| Work Time (h) | 24h |
Product Description
solar energy system PV charge controller 96V-30A/50A/100A/200A
PERFORMANCE FEATURES:
n Adopt PWM multistep sequential limiting current charge method, auto control multiple solar array connection or shut off orderly according to the battery group voltage change tendency.
n Adopt multiple-circuit charging-control circuit and individual killer switch on each circuit.
n With auto protection function of over charge, electronic short circuit, anti-reverse protection. Prevent the battery group reverse charging to the solar panel array at night.
n Big intuitionistic LCD screen shows the working status of solar panels, battery and controller. (the voltage, current, power of solar energy panel and battery)
n Power switch driving circuit is completely isolated from sampling circuit. The control signals is transmitted by opto isolation, with super-high disturbence rejection and stability.
n There are lightning protection device inside the controller. Limit instantaneous overvoltage which entered into solar panels under a level which the system can withstand; or unload the strong lightning current to the ground. To protect the equipment from lightning surge.
n Adopts the industrial-grade chips for all control, which can work under the cold, hot, humid conditions.
n Temperature compensation function. Compensate the temperature according different battery type.
n Fixable communication solution with RS-232, RS-485,USB,GPRS,Etherner,etc.
Technical parameters for 96V solar charge controller
Model | 96V30A | 96V50A | 96V100A | 96V200A | ||
Battery group rated voltage | 96Vdc | 96Vdc | 96Vdc | 96Vdc | ||
PV open circuit voltage | 400V | 400V | 400V | 400V | ||
PV Rated current | 30A | 50A | 100A | 200A | ||
PV Max. power | 2880Wp | 4800Wp | 9600Wp | 19200Wp | ||
Input PV module road number | 1 | 1 | 1/2 | 1/2 | ||
Function | Auto stop charge, auto recharge voltage; Protection: connecting contrary, over current, short circuit, over heat etc. | |||||
Display mode | LCD | |||||
Display content | solar panel voltage, solar panel current, solar panel power, battery voltage, charge current | |||||
Floating Charge Voltage (adjustable) | 110Vdc | 110Vdc | 110Vdc | 110Vdc | ||
Stop charge voltage | 116Vdc | 116Vdc | 116Vdc | 116Vdc | ||
Recharge voltage | 108V | 108V | 108V | 108V | ||
Voltage drop between PV and battery | 1.5V | |||||
Max itself power consumption | 100mA-150mA | |||||
Work environment temperature | -30-60°C | |||||
Relative humidity | <90% No condensation | |||||
Applicable altitude | <3000m The rated power should be reduced when it is higher than 2000m | |||||
Noise (1m) | <40dB | |||||
Degree of protection | IP20(Indoor) | |||||
Cooling method | Forced air cooling | |||||
*Communication interface (optional) | RS485/USB/GPRS/Ethernet | |||||
*Temperature compensation(optional) | -4mv/°C/2V,-35°C~+80°C,Accuracy:±1°C | |||||
Product size (mm) | 520*430*200 | 760*600*180 | 585*585*980 | |||
Weight | 10Kg | 26Kg | 55Kg | |||
*Above parameter only for reference. Could be custom made to user specifications.
Q 1. What's the payment term?
A. We accept TT,Western Union,Paypal,MoneyGram.
Q 2.How's the delivery time ?
A. Is due to order quantity, usually it will take about 3-7days for sample production,
Q 3.Tell me the standard of package?
A. For the small capacity, it use carton, but for big capacity, we should use honeycomb carton and pallet or wooden case for protection.
Q 4.Would you accept to use our logo ?
A.It's no problem to do OEM.
Q 5.We want to know month capacity.
A. It depends on which model.For example for relay type small capacity , month capacity can reach near 2000pcs and big capacity near 500pcs.
Q 6.Where is your market?
A. Our products are popular in Australia,South America,Philippines,Italy, America, Pakistan and so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation.
Q 7. What kind of certificate you have ?
A. Our company already achieve ISO9001, and for products, we have CE, SAA, G83 G59 etc .
Q 8. What is the warranty period ?
A. Normally 1 year ,if order quantity enough can be extended to 3 years.
Q 8.How about the lifetime?
A:The life time for inverterl is 15-20years.
OEM Services
1.Logo
Please offer us your own high resolution logo in JPG format,there should be two colors at most in the logo and there should be no gradient effect in the logo.
2.Label
Please offer us your own model numbers.
3. Manual
Please offer us the finished manual file that can be printed directly.
Lead Time
1.Sample orders will be delivered from our factory within 3-7 working days.
2.General orders will be delivered from our factory within 15-30working days.
3.Big orders will be delivered from our factory within 45 working days at most
Shipment
1.By EMS,DHL,FedEx,TNT,UPS or other express.
2.By our forwarding agent(by air or by sea).
3.By your own forwarding agent.
4.By domestic forwarding agents to any city in China.
