China Manufacturer High Power off Grid Inverter for Solar System
- NINGBO OR SHENGZHEN OR SHANGHAI
- T/T Money Gram Credit Card
You May Like
-
China Manufacturer High Quality 200kw off Grid Solar Inverter
-
Large Power 3-phase Pure Sine Wave Solar Inverter for Industrial System
-
Hybrid System High Quality DC to AC Pure Sine Wave Solar Inverter
-
15000 Watt Without Battery MPPT100-500VDC 3 Phase off Grid Inverter
-
120VDC to 380V 3-phase Solar Power Inverter for 5kw Hybrid System
-
IP45 40kw 3 Phase Solar System Pure Sine Wave Hybrid Inverter
Product Details
| Place of Origin | Zhejiang, China | Brand Name | BANGZHAO or OEM | |
| Model Number | BZP-100KW | Specification | Normal | |
| Application | Industrial | Output Voltage (V) | 380v or 415v or 440v | |
| Load Power (W) | 100kw | Solar Power (W) | 100k | |
| Work Time (h) | 24h |
Product Description
China manufacturer high power off grid inverter for solar system
We can make products according to your requirements.
cal Features:
1, Two kinds of start mode: Reduction Voltage Start and Variable Frequency Start. Customers can set start mode according to the type of the load.
2, The output frequency can be set, this function is very convenient for customer.
3, The output voltage can be set between +20 % to -40 % of rated voltage. It’s a great convenience to users.
4, The DC input voltage range can also be set. Over-voltage point, under-voltage point, over-voltage recovery point, under-voltage recovery point all can be set via the LCD panel. Convenient for increasing or reducing the quantity of batteries, photovoltaic modules also can be used flexibly.
5, Pure sine wave output. with good transient response less than 40MS, little harmonic distortion, higher conversion efficiency and stable output voltage.
6, Powerful data display and fault instruction function. LCD can display the DC input voltage, output frequency, phase voltage, phase current, AC bypass input voltage, output power KWH, time and date, temperature, fault code display.
7, Using the fifth generation efficient IPM intelligent module from Japanese Mitsubishi, high efficiency and stable performance. It with powerful protection function, the protection for short circuit, over load, over temperature is more safe and reliable. It’s service life can up to 15 years or more.
8, Wide input voltage can be set according to customer’s requirement. Input voltage range can be selected from 100-500V or 200-850V.
9, Product have passed the European CE (EMC and LVD) certificated and accredited by Australia CEC energy network.
Technical Data
BZP-100KW | ||
Isolation mode | Low Frequency Transformer | |
DC Input | Rated voltage (Vdc) | 480V |
Rated current(A) | 312.5A | |
AC Output | Rated output power | 100KW |
Output waveform | Pure Sine Wave | |
Rated Voltage | 380VAC±3% | |
Phases | 3 phase 4 wire | |
Rated current(A) | 152A (phase current) | |
Frequency | 50Hz or 60Hz | |
Rated output voltage range (V) | 380/400/415/440VAC optional | |
Power Factor(PF) | 0.9 | |
Overload Ability | 150%, 5 seconds | |
Efficiency | >93% | |
Waveform distortion rate (THD) | <3% linear load | |
Dynamic Response (0 to 100% load) | 5%,≤50ms | |
Display | LCD | |
Running mode | Working continuously | |
Electrical insulation properties | 2000Vac, 1 Minute | |
Protection Function | Protection | Input reverse polarity, under voltage, overvoltage, output over-current, short circuit, overheating etc. |
Cooling method | Fan-cooled | |
Short-circuit protection | No automatic recovery, need to restart the machine | |
Working environment | Noise ( 1 meter) | ≤50dB |
Degree of protection | IP20(indoor) | |
Working Altitude(m) | ≤2000 | |
Working temperature | -25~+55℃ | |
relative humidity | 0~90%,non-condensing | |
Mechanical dimension | Depth* Width * Height | 900x1100x1600mm |
Weight (Kg) | 600Kg | |
Above parameter only for reference ,could be custom made to user specifications.
Q 1. What's the payment term?
A. We accept TT,Western Union,Paypal,MoneyGram.
Q 2.How's the delivery time ?
A. Is due to order quantity, usually it will take about 3-7days for sample production,
Q 3.Tell me the standard of package?
A. For the small capacity, it use carton, but for big capacity, we should use honeycomb carton and pallet or wooden case for protection.
Q 4.Would you accept to use our logo ?
A.It's no problem to do OEM.
Q 5.We want to know month capacity.
A. It depends on which model.For example for relay type small capacity , month capacity can reach near 2000pcs and big capacity near 500pcs.
Q 6.Where is your market?
A. Our products are popular in Australia,South America,Philippines,Italy, America, Pakistan and so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation.
Q 7. What kind of certificate you have ?
A. Our company already achieve ISO9001, and for products, we have CE, SAA, G83 G59 etc .
Q 8. What is the warranty period ?
A. Normally 1 year ,if order quantity enough can be extended to 3 years.
Q 8.How about the lifetime?
A:The life time for inverterl is 15-20years.
OEM Services
1.Logo
Please offer us your own high resolution logo in JPG format,there should be two colors at most in the logo and there should be no gradient effect in the logo.
2.Label
Please offer us your own model numbers.
3. Manual
Please offer us the finished manual file that can be printed directly.
Lead Time
1.Sample orders will be delivered from our factory within 3-7 working days.
2.General orders will be delivered from our factory within 15-30working days.
3.Big orders will be delivered from our factory within 45 working days at most
Shipment
1.By EMS,DHL,FedEx,TNT,UPS or other express.
2.By our forwarding agent(by air or by sea).
3.By your own forwarding agent.
4.By domestic forwarding agents to any city in China.
