Sub Rack 30A 1U Switching Power System (rectifier )with Metal Panel

Name: Sub Rack 30A 1U Switching Power System (rectifier )with Metal Panel
Brand: Jetpower
SKU: 129448803
Availability: InStock

Sub Rack 30A 1U Switching Power System (rectifier )with Metal Panel thumbnail-1

Sub Rack 30A 1U Switching Power System (rectifier )with Metal Panel photo-1

US$ 10 - 150 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Jetpower

Model Number:

SPS30-48

Contact Supplier Request Quote Chat Now

Qingdao Powtech Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Jetpower

Model Number SPS30-48

Output Power Other, >500W

Output Type Other, DC power

Input Voltage 220V

Output Voltage 48Vdc

Output Frequency 50/60Hz

Output Current 30A

Product Description

sub rack 1U 30A swithing power system (metal panel)

Product features:

1U high 19”, with 1pcs controller and 2pcs*15A rectifier module (metal panel)

Controller model: CAS-03-H5230R1

Sizes: 482×260×44mm
System capacity:15~30A
AC input: 220Vac, 1phase/3wire
DC distribution: 1* 30A load

1*30A Battery
4* Alarm relay:

Controller module: with RS232/RS485 port, LCD display
Rectifier module qty: 1~2pcs

Tech. specs

Model	SPS30-48/MR4815	SPS30-48/MR4815M	SPS60-48/CR4830	SPS90-48/CR4830	SPS90-48A/CR4830 B	SPS120-48A/CR4830 B	WPS30-48/MR4815
Input voltage	176~300Vac	176~300Vac	176~300Vac	176~300Vac	176~300Vac	176~300Vac	176~300Vac
Output voltage	42~58 Vdc	42~58 Vdc	42~58 Vdc	42~58 Vdc	42~58 Vdc	42~58 Vdc	42~58 Vdc
Output current (A)	30A	30A	60A	90A	90A	120A	30A
Rated output power:	1600W	1600W	3200W	4800W	4800W	6400W	1600W
Load regulation	≤0.5%	≤0.5%	≤0.5%	≤0.5%	≤0.5%	≤0.5%	≤0.5%
Voltage regulation	≤0.5%	≤0.5%	≤0.5%	≤0.5%	≤0.5%	≤0.5%	≤0.5%
Operating temperature	-40℃ ~75℃	-40℃ ~75℃	-40℃ ~75℃	-40℃ ~75℃	-40℃ ~75℃	-40℃ ~75℃	-40℃ ~75℃
Relative humidity	90% RH	90% RH	90% RH	90% RH	90% RH	90% RH	90% RH
Dimension	48226044mm Plastic panel	48226044mm Metal panel	48226044mm	482290132mm	48229088mm	482300176mm	560250680mm (wall-mount)
Communication	RS232/RS485	RS232/RS485	RS232/RS485	RS232/RS485	RS232/RS485	RS232/RS485	RS232/RS485
Standard	JL60950/EN60950, EN55022, RoHS	JL60950/EN60950, EN55022, RoHS	JL60950/EN60950, EN55022, RoHS	JL60950/EN60950, EN55022, RoHS	JL60950/EN60950, EN55022, RoHS	JL60950/EN60950, EN55022, RoHS	JL60950/EN60950, EN55022, RoHS
DC distribution	1* 30A load 130A Batt 4 Alarm relay	1* 30A load 130A Batt 4 Alarm relay	1* 60A load 160A Batt 4 Alarm relay	4* 32A/1P load, 4* 16A/1P load 2* 63A/1P Batt or 1* 100A/1P Batt 4* alarm relay	4pcs* 30A/1P load 1pcs* 70A/1P Batt 4pcs * alarm relay	2pcs* 63A/1P load; 4pcs32A/1P load; 4pcs16A/1P load 2pcs * 100A/1P Batt 4pcs * alarm rely	24V/100W, 12V/150W 11pcs* 32A/2P Batt 4pcs *alarm relay
