switching power system 30A switching rectifier outdoor Wall-mount
- 10000 Piece / Pieces per Month
- Qingdao port
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | Jetpower | Model Number: | WPS30-48/MR4815 |
Output Power: | Other, >500W | Output Type: | Other, DC power | Input Voltage: | 220V |
Output Voltage: | 48Vdc | Output Frequency: | 50/60Hz | Output Current: | 30A |
Product Description
Product Description
Wall-mount 30A rectifier system
Outdoor wall-mount, with 1controller and 2pcs*15A rectifier module
Rectifier module model: CR4830
Controller model: CAS-03-H5230R0
Sizes: 482×260×44mm
System capacity:30~60A
AC input: 220Vac, 1phase/3wire
DC distribution: 1* 60A load
1*60A Battery
4* Alarm relay:
Controller module: with RS232/RS485 port, LCD display
Rectifier module qty: 1~2pcs
Tech. specs
Model | SPS30-48/MR4815 | SPS30-48/MR4815M | SPS60-48/CR4830 | SPS90-48/CR4830 | SPS90-48A/CR4830 B | SPS120-48A/CR4830 B | WPS30-48/MR4815 |
Input voltage | 176~300Vac | 176~300Vac | 176~300Vac | 176~300Vac | 176~300Vac | 176~300Vac | 176~300Vac |
Output voltage | 42~58 Vdc | 42~58 Vdc | 42~58 Vdc | 42~58 Vdc | 42~58 Vdc | 42~58 Vdc | 42~58 Vdc |
Output current (A) | 30A | 30A | 60A | 90A | 90A | 120A | 30A |
Rated output power: | 1600W | 1600W | 3200W | 4800W | 4800W | 6400W | 1600W |
Load regulation | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% |
Voltage regulation | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% |
Operating temperature | -40℃ ~75℃ | -40℃ ~75℃ | -40℃ ~75℃ | -40℃ ~75℃ | -40℃ ~75℃ | -40℃ ~75℃ | -40℃ ~75℃ |
Relative humidity | 90% RH | 90% RH | 90% RH | 90% RH | 90% RH | 90% RH | 90% RH |
Dimension | 482*260*44mm Plastic panel | 482*260*44mm Metal panel | 482*260*44mm | 482*290*132mm | 482*290*88mm | 482*300*176mm | 560*250*680mm (wall-mount) |
Communication | RS232/RS485 | RS232/RS485 | RS232/RS485 | RS232/RS485 | RS232/RS485 | RS232/RS485 | RS232/RS485 |
Standard | JL60950/EN60950, EN55022, RoHS | JL60950/EN60950, EN55022, RoHS | JL60950/EN60950, EN55022, RoHS | JL60950/EN60950, EN55022, RoHS | JL60950/EN60950, EN55022, RoHS | JL60950/EN60950, EN55022, RoHS | JL60950/EN60950, EN55022, RoHS |
DC distribution | 1* 30A load 1*30A Batt 4* Alarm relay | 1* 30A load 1*30A Batt 4* Alarm relay | 1* 60A load 1*60A Batt 4* Alarm relay | 4* 32A/1P load, 4* 16A/1P load 2* 63A/1P Batt or 1* 100A/1P Batt 4* alarm relay | 4pcs* 30A/1P load 1pcs* 70A/1P Batt 4pcs * alarm relay | 2pcs* 63A/1P load; 4pcs*32A/1P load; 4pcs*16A/1P load 2pcs * 100A/1P Batt 4pcs * alarm rely | 24V/100W, 12V/150W 11pcs* 32A/2P Batt 4pcs *alarm relay |
1.Major manufacturer,Competitive price
2. ISO9001:2008 certification
3. 20 years' production experience
4. Turn-key solution for your transmission line
1. Abroad site installation & training available any time
2. Best prices compared to same configuration
3. Customized product available
4. Good after-sale response
5. Small order accepted
6. Excellent workmanship
