Online UPS 40KVA/3Phase

Online UPS 40KVA/3Phase thumbnail-1
Online UPS 40KVA/3Phase photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Model Number:
MPT
Phase:
Three Phase
Contact Supplier Request Quote Chat Now
Qingdao Powtech Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Model Number MPT
Phase Three Phase
Protection Unbalanced Loads
Output Voltage 380VAC
Type Other, On-line, Low frequency
Application Medical

Specifications

1.Input: 380Vac +/-25%, 3phase
2. Out: 380Vac/3phase
3. Isolation transformer on output
4.Parallel and redundant function

UPS: Low Frequence Online UPS



MPT Series are designed to protect large critical applications such as data processing centers, mainframes, manufacturing and telecommunications systems Using online double conversion IGBT technology and two built-in INTEL microprocessors, MPTseries guarantee a perfect sine wave output with stabilized voltage and frequency. Remote control and tele-control via modem provide remote monitoring and control and provide high levels of reliability



The MPT series are parallel redundant (up to 8 units) by means of a sophisticated logic control system. A wide range of matching battery cabinets are available for extended runtime. Other options include harmonic suppression filters.





Power (kVA)

10

15

20

30

40

60

80

100

120

Input

Nominal voltage

400Vac, three phase

Voltage range

+/-20%

Frequency range

45~65Hz

Power factor

>0.92

Current THD

<5%

Soft startup

10seconds

Bypass

Nominal voltage

230Vac, single phase

Allowable voltage

+/-15% (+/-10% ~ +/-25%, settable thru LCD)

Nominal frequency

50/60Hz (auto sense)

Allowable frequency

+/-2% (+/-1% ~+/-5%, settable thru LCD)

Battery

Voltage

384Vdc

480Vdc

Max. charge current

0.2 * C10

Output

Rated power (kVA)

10

15

20

30

40

60

80

100

120

Active power (kW)

8

12

16

24

32

48

64

80

96

Nominal voltage

400Vac, three phase/5wire (348~424, settable)

Voltage regulation

+/-1% (static); +/-5% (dynamic)

Nominal current (A)

14

22

29

43

58

87

115

145

174

Frequency

50/60Hz (settable)

Frequency regulation

+/-0.05% (Battery mode); +/-2% (AC normal, settable from +/-1% to +/-5%)

Crest ratio

3:1

Wave form

True sine wave

Overload

110% for 5hrs, 125% for 10mintues, 150% for 1mintues

Interface

Contact relay

Dry contact relay

Comm.

RS-232

Remote control

Emergency power off, bypass

Noise

54dBA, 1m

60dBA, 1m

65dBA, 1m

Protection

IP20

Ambient

Temperature: 0~40, <95% no condensation

Efficiency

>90%

>91%

>92%

Safety & EMC

Safety: EN62040-1;  EMC: EN62040-2 ClassA 73/23-93/68-89/336 EEC EN62040-3

Physical

Weight(kg)

210

220

230

282

330

450

555

650

730

Size (H*W*D,mm)

1200*555*720

1400*800*740

1400*1070*740
