RFID TK4100 125KHz pvc card/smart RFID gift card for jewelry store

RFID TK4100 125KHz pvc card/smart RFID gift card for jewelry store

Gift card, a system of the marketing business model. It contains 2 main systems, magnetic stripe and RFID microchip.

There are different amount printed on the surface of the card, then it can be used as cash. It is similar with credit card, only it just can be used in specific place.

Size:

Basically, there are 2 standard sizes for gift cards, which is CR80 and CR50.

CR80: 86*54*0.76mm (3 3/8*2 1/8”, thickness 30 mil)

CR50: 85.6*43.8*0.76mm (3 1/2*1 23/32”, thickness 30 mil)

Besides, break away card (combo card) and 3-up key tags are also available for gift cards;

Break away card: 85.5+28.5*54mm, 85.5+28+28*54mm, 60+25.5*54mm

3-up key tags: 85.6(3*28.54mm)*54*0.76mm, with a hole on each tag

Customized size is available.

Card type:

1. Magnetic

There are two main systems of gift card, magnetic and RFID.

Magnetic system (two categories):

Loco: 300 Oe, 600 Oe; Hico: 2750 Oe

Loco is a more popular option for gift cards.

2. RFID

RFID system (three categories):

LF: 125 KHz; HF: 13.56 MHz; UHF: 860-960 MHz

Frequently-used chips for gift card are:

LF (125 KHz)

1_ EM4200 (Memory size: 128 bits)

2_ ATA5577 (Memory size: 363 bits)

3_ TK4100 (Memory size: 256 bits)

HF (13.56 MHz)

As one of the prepaid cards which can be used not only in entity store, such as supermarket, jewelry store, salon, flower store, toy store, book shop, you can see lots of these stores have some gift and reward cards that have some money in it, which can be rewards for clients, members and also can be a wonderful gift for relatives, and you can realize that is also a wonderful advertisement for promotion.

And also you can notice that nowadays we not only have the entity store gift cards, but also the online store gift card like amazon gift card, iTunes gift cards. You can purchase some products from online shop. Sometimes when you receive the package, you can find out that there are gift cards sent by shop owners that you can use them as cash next time.

Craft:

As the gift card typically have barcode (serial number) and magnetic stripe (chip), it could be encoded to associate with each other. Encoding the same data of the barcode (serial number) into the magnetic stripe (chip). When you scan a card, the data in the magnetic stripe appears the same on the card.

Available Crafts:

Hot stamp (gold/silver/red), Laser silver/gold, Laser Engraving, Ink jet printing, Scratch off panel, Barcode/QR code, Thermal printing, Hologram, Embossing, Adhesive sheet, UV ink, Hologram, Hole punch, etc.

Printing equipment:

Heidelberg offset printing machine

Printing effect:

Nexqo understands Printing is key issue to meet client’s satisfactions. Therefore Nexqo prints cards strictly according to client’s layout. Keeping the consistency between printing effect and approved layout is always the priority to Nexqo.

QC:

Every single card will be carefully checked by machine or manual work before dispatched.

Certificate:

Nexqo is member of ICMA (International Card Manufacturer Association) and delivers outstanding quality that has been certified in accordance with CE FCC and RoHS certificates.

Specialty:

Nexqo is member of ICMA (International Card Manufacturer Association) and delivers outstanding quality that has been certified in accordance with CE FCC and RoHS certificates.

PVC Cards are more and more widely used in many applications, such as promoting, marketing, loyalty, hospitality, etc. With bringing convenience to people, it also increases white pollution damage to environment. Nexqo researches and develops green pvc material named NexPVC^®. NexPVC^®is a 100% oxo biodegradablepvc, it could biodegrade in a landfill condition without creating methane gas even in an oxygen-free environment.

NexPVC^®had passed the test (ASTM D3826& ASTM D 5208-1) of The American Society of Testing and Materials and got the certificate from GEMA.

Package:

To make sure cards can be delivered without any damage, Nexqo uses top standard packaging. All Paper boxes and cartons are made of high-quality material.

For standard size (3-3/8”*2-1/8”):

1.Inner Box: 440*100*40mm, 500 pcs /box, 3kg

Outer Carton: 460*130*110mm, 1000 pcs/carton, 7kg

2.Inner Box: 210*100*60mm, 200 pcs/box, 1.5kg

Outer Carton: 480*230*140mm, 2000 pcs/carton, 14kg.
