Active 2.45G RFID reader with long range reading distance
A RFID reader is a device that can wirelessly communicate with RFID tags. It can detect the presence of RFID tags as well as send and receive data and commands from the RFID tags. Typically RFID Reader comprises RF module (sender and receiver), control unit and antenna.
The 2.45GHz RFID reader, with long reading range, strong penetrability and high performance, is the first choice for automated intelligent management.
Model No. |
Nex-3004A |
Operation Frequency |
2.4GHz-2.5GHz ISM microwave band |
Communication mode |
dynamically encrypt mode |
Wireless Transmission Rate |
1MBps |
Signal modulation mode |
GFSK |
Operation Mode |
Read tag only |
Microwave Communication wrong-checked |
CRC8cycled redundance checkout |
Receiving sensitivity |
-90dbm |
Identify Mode |
Directional identification, level 60°,vertical 60° |
Identified distance |
Longest 80m(distance is adjustable) |
Identify Speed |
200KM/h |
Anti-collision |
>50pcs tags/cards at one time |
Wrong probability |
one of ten million |
Sound indicating |
Buzzer inside |
Developing Interface |
offer all types of port function |
Data interface |
Standard:RS232,RS485,Wiegand 26/34 WIFI or RJ45 (custom made) |
Power supply |
DC+9V |
Working Temperature |
-40℃~+85℃ |
Nex-3004A is a type of 2.45GHz Directional Integration reader, applying in wide alleyway, far distance, quick identification, meeting the special demand of identification, tracking and reading many tags simultaneously.
With Aluminium alloy shell and other specific technical design, the 2.45GHz Directional Integration Reader is lightning protection and anti-impact. Besides, it can meet requirements for industrial environment use. Also, its’ high performance in stability and far distance reading make it possible to be applied in various fields.
Applications:
1. Alleyway management: open entrance and exit control management system, intelligent resident district and mansion parking-lot charge, freeway ETC, safety-inspection and custom
2. Personnel management: quick attendance administration, conference signature system, student safety short message system, security patrol system.
3. Cargo management: storage and data collection system, flowing goods control and tracing, container automatic identification and register management.
4. Prevention management: personnel positioning, tracing and inquiry in the mine, and Good counterfeit-proof test.
5. Public management: city intelligent traffic platform, vehicle monitor and operation, train automatic numbering
6. Manufacture management: work flow management, monitor parts in the production process.
7. Transportation management: road, railway management, and container transfer monitor and tracing management.
With high quality antenna embedded, the reader’s reading distance can reach 80m, meets requirements for many situations, such as car access control, parking management, intelligent vehicle monitor and operation.
Package:
To make sure this kind of 2.45GHz Directional Integration RFID reader can be delivered without any damage, Nexqo uses top standard packaging. All Paper boxes and cartons are made of high-quality material.
Factory:
You are welcome to visit our company.
