Product Details
Place of Origin: | Shandong, China | Brand Name: | JETPOWER | Model Number: | ND110-1210 |
Output Power: | 1 - 200KW | Output Type: | Single | Size: | 440*450*177 |
Weight: | 30 | Input Voltage: | 110Vdc | Output Voltage: | 220Vac |
Type: | DC/AC Inverters | Output Frequency: | 50/60Hz | Output Current: | 3.6A |
Product Description
1.Advance IGBT inverted technology
2.Multiple CPU intelligent control
3.Multiple protection function of over-voltage ,short circuit, over-temperature on input
4.Special industrial design to ensure the safety in worse environment
5.Reliable, filtering and stable sine wave output
6.Static bypass switch
7.with output isolation transformer
8.LCD+LED display
9.19inch rack (for 5kva and below)
110VDC/AC inverter (1phase output) | ||||||||||
Model | ND 110 | ND110 | ND110 | ND110 | ND110 | ND110 | ND110 | ND110 | ND110 | |
-1010 | -1020 | -1030 | -1050 | -1060 | -1100 | -1150 | -1200 | -1300 | ||
DC input | Rated DC input voltage (VDC) | 110 | ||||||||
Rated DC input current (A) | 10 | 20 | 32.6 | 50 | 55 | 98 | 148 | 198 | 296 | |
DC input voltage range (VDC) | 88~132Vdc | |||||||||
Bypass | Utility AC input voltage (VAC) | 220Vac±20%, 50Hz±10% | ||||||||
Utility | Rated AC input voltage (A) | 4.55 | 9.1 | 13.65 | 22.75 | 27.25 | 45.5 | 68.25 | 91 | 136.5 |
input | Bypass transfer time (ms) | ≤4 | ||||||||
AC output | Rated capacity (KVA) | 1 | 2 | 3 | 5 | 6 | 10 | 15 | 20 | 30 |
Rated output power (KW) | 0.8 | 1.6 | 2.4 | 4 | 4.8 | 8 | 12 | 16 | 24 | |
Rated output voltage and frequency | 220VAC, 50HZ | |||||||||
Rated output current (A) | 3.6 | 7.3 | 11 | 18.2 | 21.82 | 36.4 | 54.6 | 72.7 | 109 | |
Output voltage regulation (V) | 220Vac±2% | |||||||||
Output frequency regulation(Hz) | 50±1% | |||||||||
THD | ≤3% | |||||||||
Dynamic response (load 0←→100%) | 5% | |||||||||
Power factor | 0.8 | |||||||||
Overload | 150%,60s | |||||||||
Crest factor | 03:01 | |||||||||
Efficiency at rated load | 90% | 92% | ||||||||
Environment | Insulation strength (between input & output) | 1500VAC, 1min | ||||||||
Noise (1m) | ≤50dB | |||||||||
Temperature | -10℃~+50℃ | |||||||||
Humidity | 0~90%, no condensation | |||||||||
Altitude (m) | ≤2000 | |||||||||
Sizes | Rack tye (W* D * H, mm) | 440×450×177 | 440×450×177 | 440×450×177 | 440×500×221.5 | 440×500×221.5 | 330×640×885 | 330×640×885 | 330×680×935 | 490×985×1206 |
Weight (kg) | 30 | 50 | 55 | 70 | 80 | 122 | 158 | 175 | 270 | |
Protection | DC input reversely protection, DC input under voltage,over voltage, overload, short circuit, over temperature |
