Home > Products > Inverter > 50k 40kw 220V DC/AC power inverter(2k,5k,7.5k,10k,15k,20k,30k,40k,50k)/DC to AC inverter/3 phase output inverter
50k 40kw 220V DC/AC power inverter(2k,5k,7.5k,10k,15k,20k,30k,40k,50k)/DC to AC inverter/3 phase output inverter
USD $1,200 - $1,400
/ Unit
1 Unit(Min.Order)
- 800 Ton / Tons per Month
- Qingdao
- T/T L/C D/P D/A Credit Card
You May Like
-
electric ac motor speed controller 480V 32A 18kw 3phase Input&3Phase Output AC frequency converter with 18 months warranty
-
45kw 380v vector control ac frequency converter 50hz 60hz motor frequency inverter 3 phase Power Frequency Converter for Pump
-
EM15-G3 General used Vector control Frequency inverter(3 phase )
-
EMHEATER soft starter
-
EM GS2 7.5KW 220V 240V Motor Soft Starter for Submersible Pump deep well
-
Inverter AB PowerFlex®7 Converter 22CD012N103 Inverter PowerFlex 400- 5.5 kW (7.5 HP) AC Drive
Product Details
| Place of Origin: | Shandong, China | Brand Name: | JETPOWER | Model Number: | ND220-3500 |
| Output Power: | 1 - 200KW | Output Type: | Triple | Size: | 490*985*1205 |
| Weight: | 450 | Input Voltage: | 220VDC | Output Voltage: | 220VAC |
| Type: | DC/AC Inverters | Output Frequency: | 50/60Hz | Output Current: | 140A |
Product Description
50k 40kw 220V DC/AC 3 phase power inverter
Product Description
220V DC/AC 50k,40kw power inverter( 2k,5k,7.5k,10k,15k,20k,30k,40k,50k/DC to AC inverter/3 phase output inverter
Features:
1.Advance IGBT inverted technology
2.Multiple CPU intelligent control
3.Multiple protection function of over-voltage ,short circuit, over-temperature on input
4.Special industrial design to ensure the safety in worse environment
5.Reliable, filtering and stable sine wave output
6.Static bypass switch
7.With output isolation transformer
Detailed Images
Tech. specs
| 220VDC/AC inverter (3 phase output) | ||||||||||
| Model | ND220 | ND220 | ND220 | ND220 | ND220 | ND220 | ND220 | ND220 | ND220 | |
| -3020 | -3050 | -3075 | -3100 | -3150 | -3200 | -3300 | -3400 | -3500 | ||
| DC input | Rated DC input voltage (VDC) | 220Vdc | ||||||||
| Rated DC input current (A) | 10.1 | 25..3 | 34.1 | 49.4 | 74.2 | 99 | 148.5 | 185.25 | 230 | |
| DC input voltage range (VDC) | 180~300Vdc | |||||||||
| AC bypass input | Utility AC input voltage (VAC) | 220Vac±20% | ||||||||
| Rated AC input current (A) | 6 | 15 | 22 | 30 | 45 | 60 | 90 | 120 | 140 | |
| Bypass transfer time (ms) | ≤4 | |||||||||
| AC output | Rated capacity (KVA) | 2KVA | 5KVA | 7.5KVA | 10KVA | 15KVA | 20KVA | 30KVA | 40KVA | 50KVA |
| Rated output power (KW) | 1.6 | 4 | 6 | 8 | 12 | 16 | 24 | 32 | 40 | |
| Rated output voltage and frequency | 220VAC ,50Hz (3phase, 4wire) | |||||||||
| Rated output current (A) | 6 | 15 | 22 | 30 | 45 | 60 | 90 | 120 | 140 | |
| Output voltage regulation (V) | 220Vac ±3% | |||||||||
| Output frequency regulation(Hz) | 50Hz±0.05 | |||||||||
| THD | ≤2% | |||||||||
| 3phase unbalanced | ≤100% | |||||||||
| Dynamic response (load 0←→100%) | 5% | |||||||||
| Power factor | 0.8 | |||||||||
| Overload | 150%, 10S | |||||||||
| Crest factor | 3:01 | |||||||||
| Efficiency at rated load | 91% | 92% | ||||||||
| Environment | Insulation strength (between input & output) | 2000VAC,1min | ||||||||
| Noise (1m) | ≤45dB | |||||||||
| Temperature | -10℃~+50℃ | |||||||||
| Humidity | 0~90%, no condensation | |||||||||
| Altitude (m) | ≤2000 | |||||||||
| Sizes | W* D * H, mm | 440×450×177 | 440×500×221.5 | 330×640×885 | 330×640×885 | 330×640×885 | 380×680×935 | 410×720×935 | 490×985×1205 | 490×985×1205 |
| Weight (kg) | 45 | 60 | 110 | 112 | 145 | 160 | 250 | 400 | 450 | |
| Protection | DC input reversely protection, DC input under voltage, overload, short circuit, over temperature | |||||||||
