DC to AC inverter / 20K 16KW 115V 1 phase inverter/115V power inverter (1K,2K,3K,4k,5K,6k,10K,15k,20K,30K)

FOB Price

USD $900 - $1,000 / Unit

1 Unit(Min.Order)

Supply Ability 800 Unit / Units per Month
Port Qingdao
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Shandong, China	Brand Name:	JETPOWER	Model Number:	ND110-1200
Output Power:	1 - 200KW	Output Type:	Single	Size:	330640885
Weight:	175	Input Voltage:	110VDC	Output Voltage:	115VAC
Type:	DC/AC Inverters	Output Frequency:	50/60Hz	Output Current:	139.5A

Product Description

DC to AC inverter / 20K 16KW 115V 1 phase inverter/115V power inverter (1K,2K,3K,4k,5K,6k,10K,15k,20K,30K)

Product Description

DC to AC inverter / 20K 16KW 115V 1 phase inverter/115V power inverter (1K,2K,3K,4k,5K,6k,10K,15k,20K,30K)

Features:

1.Advance IGBT inverted technology

2.Multiple CPU intelligent control

3.Multiple protection function of over-voltage ,short circuit, over-temperature on input

4.Special industrial design to ensure the safety in worse environment

5.Reliable, filtering and stable sine wave output

6.Static bypass switch

7.With output isolation transformer

8.LCD+LED display

9.19 inch rack (for 5kva and below)

Tech. specs

Model		ND 110	ND110	ND110	ND110	ND110	ND110	ND110	ND110	ND110
Model		-1010	-1020	-1030	-1040	-1050	-1100	-1150	-1200	-1300
DC input	Rated DC input voltage (V_DC)	110
	Rated DC input current (A)	10	20	32.6	43.4	50	98	148	198	296
	DC input voltage range (V_DC)	88~132Vdc
Bypass	Utility AC input voltage (V_AC)	115Vac±20%, 50Hz±10%
Utility	Rated AC input voltage (A)	8.7	17.4	26.1	34.8	43.5	87	130.4	174	261
input	Bypass transfer time (ms)	≤4
AC output	Rated capacity (KVA)	1	2	3	4	5	10	15	20	30
	Rated output power (KW)	0.8	1.6	2.4	3.2	4	8	12	16	24
	Rated output voltage and frequency	115V_AC, 50H_Z
	Rated output current (A)	6.96	13.9	20.9	27.85	34.8	69.6	104.3	139.5	208.7
	Output voltage regulation (V)	115Vac±2%
	Output frequency regulation(Hz)	50±1%
	THD	≤3%
	Dynamic response (load 0←→100%)	5%
	Power factor	0.8
	Overload	150%,60s
	Crest factor	03:01
	Efficiency at rated load	90%								92%
Environment	Insulation strength (between input & output)	1500V_AC, 1min
	Noise (1m)	≤50dB
	Temperature	-10℃~+50℃
	Humidity	0~90%, no condensation
	Altitude (m)	≤2000
Sizes	Rack tye (W* D * H, mm)	440×450×177	440×450×177	440×450×177	440×500×221.5	440×500×221.5	330×640×885	330×640×885	330×680×935	490×985×1206
Weight (kg)		30	50	55	60	70	122	158	175	270
Protection		DC input reversely protection, DC input under voltage,over voltage, overload, short circuit, over temperature
