DC to AC inverter 1 phase / 4K 3.2KW 115V 1 phase inverter(1K,2K,3K,4k,5K,6k,10K,15k,20K,30K)/115V power inverter

FOB Price

USD $300 - $450 / Unit

1 Unit(Min.Order)

Supply Ability 1000 Unit / Units per Month
Port Qingdao port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Shandong, China	Brand Name:	JETPOWER	Model Number:	ND110-1040
Output Power:	1 - 200KW	Output Type:	Single	Size:	440500221.5(mm)
Weight:	60	Input Voltage:	110VDC	Output Voltage:	115VAC
Type:	DC/AC Inverters	Output Frequency:	50/60Hz	Output Current:	34.8A

Product Description

DC to AC inverter 1 phase / 4K 3.2KW 115V 1 phase inverter(1K,2K,3K,4k,5K,6k,10K,15k,20K,30K)/115V power inverter

Product Description

Features:

1.Advanced IGBT inverted technology

2.Multiple CPU intelligent control

3.Multiple protection function of over-voltage ,short circuit, over-temperature on input

4.Special industrial design to ensure the safety in worse environment

5.Reliable, filtering and stable sine wave output

6.Static bypass switch

7.with output isolation transformer

8.LCD+LED display

9.19 inch rack (for 5kva and below)

Tech. specs

Model		ND 110	ND110	ND110	ND110	ND110	ND110	ND110	ND110	ND110
Model		-1010	-1020	-1030	-1040	-1050	-1100	-1150	-1200	-1300
DC input	Rated DC input voltage (V_DC)	110
	Rated DC input current (A)	10	20	32.6	43.4	50	98	148	198	296
	DC input voltage range (V_DC)	88~132Vdc
Bypass	Utility AC input voltage (V_AC)	115Vac±20%, 50Hz±10%
Utility	Rated AC input voltage (A)	8.7	17.4	26.1	34.8	43.5	87	130.4	174	261
input	Bypass transfer time (ms)	≤4
AC output	Rated capacity (KVA)	1	2	3	4	5	10	15	20	30
	Rated output power (KW)	0.8	1.6	2.4	3.2	4	8	12	16	24
	Rated output voltage and frequency	115V_AC, 50H_Z
	Rated output current (A)	6.96	13.9	20.9	27.85	34.8	69.6	104.3	139.5	208.7
	Output voltage regulation (V)	115Vac±2%
	Output frequency regulation(Hz)	50±1%
	THD	≤3%
	Dynamic response (load 0←→100%)	5%
	Power factor	0.8
	Overload	150%,60s
	Crest factor	03:01
	Efficiency at rated load	90%								92%
Environment	Insulation strength (between input & output)	1500V_AC, 1min
	Noise (1m)	≤50dB
	Temperature	-10℃~+50℃
	Humidity	0~90%, no condensation
	Altitude (m)	≤2000
Sizes	Rack tye (W* D * H, mm)	440×450×177	440×450×177	440×450×177	440×500×221.5	440×500×221.5	330×640×885	330×640×885	330×680×935	490×985×1206
Weight (kg)		30	50	55	60	70	122	158	175	270
Protection		DC input reversely protection, DC input under voltage,over voltage, overload, short circuit, over temperature

Certifications

Detailed Images

Packaging

Shipping

Why choose us

1. Major manufacturer,Competitive price, good quality and delivery in time

2. ISO9001:2008 certification

3. Many years' production experience

Our Services

1. Abroad site installation & training available any time

2. Best price compared to same configuration

3. Customized product available

4. Good after-sales response

5. Small order accepted

6. Excellent workmanship
