Cbb61 sh Polypropylene Capacitor

Specifications

cbb61 sh polypropylene capacitor
1.CE,CQC,UL,TUV certificate
2.different lead-out and shell
3.good self-healing
4.on time



cbb61 sh polypropylene capacitor







Technique Data
Climate Type:	40/70/21; 25/85/21
Rated Voltage:	250-450VAC
Rated Frequence:	50~60HZ
Rated Capacitance:	250VAC:0.5-40μf
	450VAC:0.5-30μf
Torelance:	±5%, ±10%
Loss Factor (tgδ):	≤0.1%(100Hz)
Over Voltage Test (T-C):	2500VAC, 10S no breakdown
Over Voltage Test (T-T):	2.0Un, 10s no breakdown
Safety Class:	P0.
Packing Details:	Standard packing cartons; 100 or 500 pcs per carton.





Features and use:

All of its performance indexes reach the requirements of IEC252 criterion. With its good self-healing characteristic, long life-span and high proportionality, it is widely used as the start-up and running capacitor that is special for electric appliances such as electric fanners, ventilators and exhaust fanners.
