Optic fiber cable/ADSS cable 600m span
ADSS cable 600m span/Optic fiber cable
Features:
1-Fiber core: 12~96fibers
2-Low attenuation coefficient and chromatic dispersion, insure cable's optics transmission charateristics
3- Proper design, precise fiber excess length control and distinct stranding process render the cable excellent mechanical and environmental characteristics
4- Anti-electromagnetism ability
5- Use high intensity aramid yarn as anti-pulling component, strong, light and small cable diameter, suitable for different climatic situation and installation span.
ADSS application:
Environment with high electric field strength in the power transmission system and area where frequent thunder happens.
ADSS standard compliance
IEEE P1222, ITU-T G.652, ITU-T G.655, IEC60794-1, DL/T 788-2001, YD/T 980-2002
ADSS technical parameter:
According fiber cores, weather condition, installation span, line voltage and etc.
ADSS Mechical characteristics:
Cable diameter: 13.6mm
Weight (kg/km): 152kg/km
Rated tensile strength: 35.6KN
Max. allowable stress: 14.2KN
Everyday stress (EDS):8.9KN
Ultimate operation stress:21.3KN
Min. bending radius: static: 15D
dynamic: 20D
1.Excellent quality
2.Favored price
3.Experienced workers team
4.Professional after-sales service
5.ADSS/OPGW cable,cable accessories leading supplier from China
6.Customized
