Overhead OPGW Cable

Name: Overhead OPGW Cable
Brand: OPTELEC
SKU: 129442797
Availability: InStock

US$ 1,000 - 2,000 MOQ: 1 Kilometer

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

OPTELEC

Model Number:

OPGW

Qingdao Powtech Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name OPTELEC

Model Number OPGW

Overhead OPGW cable

Product Description

Overhead OPGW cable

Product features:

1-Stranded design allow up to three steel tubes

2- Laser welded stainless steel tubes provide mechanical and thermal protection for optical fibers.

3-Light weight and small diameter

4-Good resistance to moisture and hydrogen ingress

Typical OPGW structure:

OPGW standard compliance

IEEE -1138, IEC60794-4-1, IEC60793, ITU-T G.652, ITU-T G.655, IEC60794-1, DL/T 788-2001, YD/T 980-2002

OPGW technical parameters:

According fiber cores, weather condition, RTS, short circuit current capacity, DC resistance, line voltage and etc.

OPGW main models:

Cable model	OPGW-60	OPGW-70	OPGW-90	OPGW-110	OPGW-130
Number /diameter(mm) of stainless steel tube	1/3.5	2/2.4	2/2.6	2/2.8	1/3.0
Number /diameter of AL wire(mm)	0/3.5	12/2.4	12/2.6	12/2.8	12/3.0
Number /diameter of ACS wire(mm)	6/3.5	5/2.4	5/2.6	5/2.8	6/3.0
Diameter of Cable (mm)	10.5	12.0	13.0	14.0	15.0
RTS(KN)	75	45	53	64	80
Cable weight (kg/km)	415	320	374	432	527
DC resistance(20⁰C W/km)	1.36	0.524	0.448	0.386	0.327
Modulus of elasticity(Gpa)	162.0	96.1	95.9	95.6	97.8
coefficient of Linear thermal expansion(1/×10^-6)	12.6	17.8	17.8	17.8	17.2
Short circuit capacity (kA²s)	24.0	57.3	78.9	105.8	150.4
Max. operation temperature ()	200	200	200	200	200
Max. fiber count	48	32	48	52	30
