gold-plated MCX male coaxial connector for PCB mounting
MCX micro-miniature RF connectors are suitable for 50 ohm applications an provide repeatable performance from DC to 6GHz. The snap on coupling feature allows ease of assembly in dense packaging layouts. The design of the connector encompasses the need for size reduction, low weight, durability, and reliable performance, which are required in RF circuits of mobile and fixed communication system.
Typical applications for MCX connectors include GPS, wireless communications and automotive.
Specification:
| Key Performance | |
| Temperature range | -65℃ ~ 155℃ |
| Insulation resistance | ≥1000MΩ |
| Characteristic impedance | 50Ω/75Ω |
| Dielectric Withstanding voltage | 750V(r ms) |
| Frequency range(50Ω) | 0~6GHz |
| Frequency range(75Ω) | 0~1.5GHz |
| VSWR (50Ω) | ≤1.20 |
| VSWR (75Ω) | ≤1.35 |
| Voltage rating | 335V(r ms) |
| Insertion loss | 0.1dB at 1GHz |
| Contact resistance Center conductor | ≤5mΩ |
| Contact resistance Outer conductor | ≤2.5mΩ |
| Durability | 500 Cycles |
| Material And Plating | |
| Body | Brass , gold plated |
| Male center contacts | Brass , gold plated |
| Female center contacts | Beryllium copper ,gold plated |
| Insulators | PTFE |
| Gaskets | Cooper alloy,nickel or gold plated |
| Crimp ferrules | Beryllium copper ,gold plated |
