Specifications
Best price pipe1)High Quality
2)Welded titanium pipe
3) Type: Round
4) Material: TiGr2,Gr3, Gr5, N02200, N02
Best price Pipes
Why choose us:
1. We can provide extrusion services for titanium alloy pipes, nickle base alloy pipes, duplex steel pipes, hastelloy pipes.
2. Our factory forms a complete set of advanced producing and processing line, including melting, forging, extruding, straightening and rolling, which allow us to well control the products quality.
application:
1. Oceaneering: evaporator, heat transmitter, exchanger,oil production platform, oil cooler, running pipe etc.
2. Thermal power engineering:condenser, heat exchanger, engine vane etc.
3. Chemical engineering:Flat plate heat exchanger, flat plate condenser, cooler tower,chloride barrels etc.
4. Bicycle and automobile exhaust tubing.
5. Vessels:Running pipes, submersible,gas cylinder, heat exchanger etc.
6. Aerospace:Engine, fan plate, gas compressor vane, rack, hatch cover, empennage etc.
| TITANIUM CHEMICAL SPECIFICATION | ||||||||||
| Alloy | Al | V | Mo | Zr | Si | N, max | C, max | H, max | Fe, max | O, max |
| Grade 1 | 0.03 | 0.1 | 0.01 | 0.2 | 0.18 | |||||
| Grade 2 | 0.03 | 0.1 | 0.01 | 0.3 | 0.25 | |||||
| Grade 3 | 0.05 | 0.1 | 0.01 | 0.3 | 0.35 | |||||
| Grade 4 | 0.05 | 0.1 | 0.01 | 0.5 | 0.4 | |||||
| Grade 5 | 5.5- 6.75 | 3.5-4.5 | 0.05 | 0.1 | 0.01 | 0.4 | 0.2 | |||
| Grade 9 | 2.5- 3.5 | 2-3 | 0.02 | 0.1 | 0.01 | 0.25 | 0.15 | |||
| Grade 23 | 5.50- 6.50 | 3.5-4.5 | 0.05 | 0.08 | 0.0125 | 0.25 | 0.13 | |||
| BT-9 | 5.8-7 | 2.8-3.8 | 1.0-2.0 | 0.2-0.35 | 0.05 | 0.1 | 0.015 | 0.25 | 0.15 | |
| Ti-3Al-2.5V | 2.5-3.5 | 2.0-3.0 | 0.02 | 0.05 | 0.015 | 0.25 | 0.12 | |||
Applications:
Industry field, aerospace, architectural, automotive, biomedical, chemical processing, marine, military, oil, tooling, racing.
(1)Heat exchangers and condensers
(2)All kinds of corrosive fluid transmission pipeline system
(3)Titanium bicycle pipe, automobile exhaust pip
(4)Offshore aquaculture
Our Advantage:
First-class product,Reasonable price,The fastest delivery
Test:
Final product test: Ultrasonic test, Eddy current test, Hydraulic test, Bend test, Flaring test and so on.Third party inspection is acceptable
Description |
Large Welded Pipe ,Large titanium pipe |
Standards |
ASTM, AISI, JIS, SUS, EN, DIN, BS, GB |
Material |
Gr1,Gr2,N4,N6,SS |
ASTM A 53: Gr. A, Gr B, Gr C, Gr.D | |
ASTM A252: Gr.1 Gr.2 Gr.3 etc | |
Type |
Round |
Outside Diameter |
Outer Diameter: 10-250000mm
Inside Diameter: 95-990mm 10mm-2500mm (1/8 inch,1/4 inch, 1/2 inch,3/4 inch, 1inch, 1 1/4 inch , 1 1/2 inch, 2inch,2 1/2 inch,3inch, 3 1/2 inch, 4inch,5 inch, 6inch, 8 inch, 10 inch, 12inch,14inch, 16 inch, 18 inch, 20 inch, 22 inch, 24 inch, 26inch, 28 inch,30 inch,32 inch, 34 inch, 36 inch, 38 inch, 40 inch, 42 inch, 44 inch, 46 inch, 48 inch) |
Thickness |
1mm~220mm (SCH5 ,SCH10,SCH20,SCH30,STD,SCH40,SCH60,XS, SCH80,SCH100,SCH120,SCH140,SCH160, XXS) |
Length |
6m, 5.8m,or as required |
Price Term |
FOB, CFR, CIF |
Package |
Wooden box, bundled for export standard or as required |
Payment Term |
T/T, L/C, |
Delivery Time |
According to customer' s quantity. |
Application |
a) General service industries (petroleum, food, chemical, paper, fertilizer, fabric, aviation and nuclear) |
Factory Photo
Equipment Capacity
Enterprise Certification
Packing and Loading
Engineering Corperation
We Offer:
1. Cost control-manufacturing and exporting by ourselves;
2. Competitive price-without middlemen;
3. Quality guarantee-SGS, Mill Test Certificate, other test as ordered;
4. On-time delivery-30 tons production capability per month and developed logistics;
5. Competitive payment method-different and flexible payment method (full L/C, 20%-70%-10%......)
Applications:
Industry field, aerospace, architectural, automotive, biomedical, chemical processing, marine, military, oil, tooling, racing.
(1)Heat exchangers and condensers
(2)All kinds of corrosive fluid transmission pipeline system
(3)Titanium bicycle pipe, automobile exhaust pip
(4)Offshore aquaculture
Our Advantage:
First-class product,Reasonable price,The fastest delivery
Test:
Final product test: Ultrasonic test, Eddy current test, Hydraulic test, Bend test, Flaring test and so on.Third party inspection is acceptable
Welcome to our factory and contact us at any time !!!
