Specialized manufacturing ceramic brick production line

Specifications

1. ceramic brick production line
2. Hydraulic
3. PLC control
4. cardan shaft tranmission

QT10-15 ceramic brick production line



5. Mixer of QT10-15 ceramic brick production line

6.  Stacker of QT10-15 plastic pallets for brick block making machine





 1.  Main Technical Specification of ceramic brick production line

Overall Size	5320*2080*2870mm
Molding Cycle	15-20S
Pallet Size	1250*880*25/30mm
Weight	15T
Rated Power	51kw
Vibration Force	120KN
Vibration frequency	2850/min
Mixer model	JS750



2.  Sample moulds testing productivity of QT10-15 ceramic brick production line :

Item	Specification（L*W*H）	Quantity/hour（PCS）	PSC/Mould
Concrete  block	390×190×190	1400-1800	10
Solid  block	240×115×53	9720-10800	54
Porous  block	240×115×90	5860-5400	27





3. Other parameters of QT10-15 ceramic brick production line :

1)Raw Materials:

crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes.

2)Applied Products:

concrte blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc.

3)Applied Fields:

widely used in buildings, road pavings, squares, gardens, landscaping, city constructions, etc.

4) Moulds capacity

Production/Mould:	10 pcs/mould (Standard Block: 390x190x190mm)
	54 pcs/mould (Solid Block: 240x115x53mm)
	20pcs/mould (Interlock Paver: 225x112.5x60mm)
	21pcs/mould (Holland Brick:200x100x60-80mm)
Production/Day     (8 Working Hours):	Hollow Block (400x200x200mm): 11200-14400pcs
	Solid Block (240x115x53mm): 77760-86400pcs
	Interlock Paver (225x112.5x60mm): 17280-21600 pcs
	Holland Brick (200x100x60-80mm): 2419230240 pcs









Pre-sale Services:

Yurui provides you with the prophase plan, process flow design and manufacture equipment according to your special demand.



Sale-Services:

Yurui sends technicians to the jobsite for guiding the installation and adjustment, commissioning , training operators and finishing the check and accept together with you, ,as well as turnkey project for customers. Your team can start your project in a best status.



After-sale Services:

We can supply after-sale service overseas. Whenever need our overseas service, we will be here.



Yurui scenery

Dear friends,to save your valuable time,please kindly add informations as follows in your inquiry:

1.The exact size of blocks and bricks you need;

2.Pictures of your blocks;

3.Capacity you need per 8 hours;
