Industiral Heavy Oil Fired Burners

industiral heavy oil fired burners

Working characters
1.The high speed hot air flow in the outlet can enhance the air circulation in the furnace, improve the uniformity of temperature, and ensure product quality.

 2.High temperature air flow enhances heating transfer, improving the production and energy efficiency of industrial furnaces.

3.With three times of air distribution, fuel atomization, well mixture, and equipped with small high-temperature combustion chamber, it achieves complete combustion without black smoke which improves energy efficiency. Energy-saving effect is remarkable.

4. With wide adjustment ratio, it can be applied to the requirements of different heating temperatures.

5. Equipped with a full set of automatic ignition, automatic adjusting flame monitor and flameout protection.

6. With automatic control valves and controllers, it can achieve fully automatic control.

Working structure and theories

The high speed temperature adjusting gas burner is composed by: fuel nozzle, combustion cylinder, combustion chamber, cover, high-pressure igniter and flame sensor.

1First, the fuel sprayed by compressed air is mixed with combustion air for two times in the combustion tube. The fuel is ignited automatically by the ignition devices in the combustion chamber and is combusted completely after mixed with the third air. At last, the high temperature air flow eject from outlet of the combustion chamber.

Automatic ignition equipment is ignited with the help of gas and then turned off automatically after ignition. 15kg liquid gas can be used for 2years.

2Burner burning capacity is controlled by specialized valve. It can achieve fully automatic operation when equipped with burner, high pressure ignition system, GSKY (Q) controller (supporting special valves and controller provided by the second Design Institute)

Operations

The burner selects valves according to the installation drawing, and equipped with GSK-Y (Q) high-speed burner combustion controller; after ignition, the flame shows, small fire and big fire control and flameout protection can be finished automatically by the controller, or access to the upper machine to achieve automatic control.

Technical specifications

We provide professional industrial furnace and industrial design as customer order.

2.How is the quality of your products?

Our products are manufactured strictly according to national and international standard, and we take a test on every grinder before delivery.

3.Guaranteed?

If products’ quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.

4.How about price?

Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that “ for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according  to quantity”.
