Specifications
It is suitable for thermoforming PS, HIPS, PVC, PET, PPand flocking sheets to produce various blister packaging and blister trayDXS-700/1200A-2 automatic computerized high speed vacuum forming machine (thermoforming machine) is designed by the principle of mechanical-electrical-pneumatic integration. It adopts PLC control system, panel and AC voltage meter adjustment. This fully automatic forming equipment is for thermoforming plastic sheets integrating feeding and heating with forming, cooling, mold ejecting and cutting. This machine features performance and convenient operation.
Applications:
It is suitable for thermoforming PS, HIPS, PVC, PET, PP and flocking sheets to produce various blister packaging and blister trays; including: egg tray,curatorial injection tray, inner linings of liquid bottles, inner linings of mobile phones, cookies trays and disposable tableware.
Main technical parameters:
1) Length of forming: 760 - 1,200mm
2) Width of forming: 500 - 700mm
3) Height of forming: 165mm
4) Production speed: 60 - 720 cycles/h
5) Power of oven: 24kw (upper), 18kw(lower)
6) Power of vacuum pump motor: 3kW
7) Vacuum pump capacity: 100cbm/h
8) Power of air compressor: 15kW
9) Air displacement of air compressor: 2cbm/min
10) Voltage: 380/220V 50Hz
11) Overall dimensions: 7,220 x 1,400 x 2,160mm
12) Weight: 3,500kg
