Help CenterDXS-700/1200A-2 Automatic High-speed Vacuum Forming Machine
Related Products
Specifications
Vacuum Formign Machine for forming PS, HIPS, PVC, PET, PP to produce egg tray, cookies trays, electric elements tray etc.DXS-700/1200A-2 automatic computerized higg-speed vacuum forming machine (thermoforming machine) is designed by the principle of mechanical-electrical-pneumatic integration. It adopts PLC control system, touch screen and AC voltage meter adjustment. This fully automatic forming equipment is for thermoforming plastic sheets integrating feeding and heating with forming, cooling, mold ejecting and cutting. This machine features performance and convenient operation.
Applications Area:
It is suitable for thermoforming PS, HIPS, PVC, PET, PP and flocking sheets to produce various blister packaging and blister trays; such as egg tray,curatorial injection tray, inner linings of liquid bottles, inner linings of mobile phones, cookies trays and disposable tableware.
Main Technical Parameters:
1) Length of forming: 760 - 1,200mm
2) Width of forming: 500 - 700mm
3) Height of forming: 165mm
4) Production speed: 60 - 720 cycles/h
5) Power of oven: 24kw (upper oven ), 18kw (lower oven)
6) Power of vacuum pump motor: 3kw
7) Pump speed of vacuum: 100cbm/h
8) Power of air compressor: 15kW
9) Air displacement of air compressor: 2cbm/min
10) Voltage: 380/220V 50Hz
11) Overall dimensions: 7,220 x 1,400 x 2,160mm
12) Weight: 3,500kg
