Specifications
Plastic clampshell forming machine special for thermoforming PVC, PET, PS,HIPS, PP plastic clampshell and blister etc...(Vacuum Forming Machine, Thermoforming Machine, Clampshell forming machine)DXS-700/1200A-1 plastic clampshell Forming Machine (Thermoforming machine) is designed by the principle of mechanical-electrical-pneumatic integration. It adopts PLC control system, panel and digital power control adjustment. This full-automatic forming equipment for thermoforming plastic sheet includes feeding, heating; forming, cooling, mold ejecting, cutting at one blow. This machine has luxury configuration and gets reliable performance and handy operation.
Application area:
It is suitable for thermoforming PS, HIPS, PVC, PET, PP, flocking sheet that can produce varieties of blister package and blister tray. For example: curatorial injection tray, oral liquid tray, mobile telephone tray, cookies tray, egg tray, clampshell, one-off tableware etc...
Main technical parameters:
Model: DXS-700/1200A-1
Length of forming 760-1200mm
Width of forming 500-700mm
Height of forming ≤165mm
Production Speed 60-720Cycles/h
Power of oven 24KW
Vacuum Pump Capacity: 100 Cube meters per hour
Power of Air Compressor: 15KW
Air Displacement of Air Compressor:2 Cube meters per min
Voltage:380/220V 50HZ
Overall Dimensions:7950*1450*2550mm
Weight 3000Kg
Sample:
