Deutz BF6L913C Engine 141kw

Deutz BF6L913C Engine 141kw photo-1
US$ 6,900 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Deutz
Model Number:
SMD, Saint Meilan
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou Port Xiamen Port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Fujian, China
Brand Name Deutz
Model Number SMD, Saint Meilan
Output Type AC Three Phase
Speed 1500RPM/1800RPM
Frequency 50/60Hz
Rated Power 10kva--1250kva
Rated Voltage 110V/240V, 220V/380V, 230V/400V, 240V/415V
Rated Current 5-2000A

Specifications

BF6L913C Deutz Engine
1.50/60Hz
2.1800-2560 rpm
3.warranty 1.5year
4.Industry and Machanical

Deutz BF6L913C Engine 141kw

1500rpm-2500rpm



102/125 mm Bore * Stroke
offset 6.128 l
141kw/2500rpm Specification
Working Sequence 1-5-3-6-2-4
Cooling Method Air cooling
rotative moment(torque) 690 N.m.
Compression Ratio 18
Net weight 510kg
Overall Dimension 1134*711*990mm
Capacity oil sump 14--20
The air flow of the combustion air (m3/min) 7.18
Supply of exhaust gas (m3/min) 7,39
Net weight 510kg
Overall Dimension 1134*711*990mm



Model Deutz F6L413F
Deutz F6L413F Induction system Naturally aspirated
Deutz F6L413F Numbers of Cylinder:6
Deutz F6L413F Type V type configruation 4-Stroke air-cooled direct injection
Deut F6L413F Displacement (L) 9.572
Deutz F6L413F Bore X Stroke (mm) 125x130
Deutz F6L413F Compression Ratio 17
Deutz F6L413F Direction of Rotation clockwise
Deutz F6L413F Speed (rpm) 2650
Deutz F6L413F Power (kw) 141
Deutz F6L413F Oil Consumption (g/kw.h) 216
Deutz F6L413F Idle Speed (rpm) 600
Deutz F6L413F Max Torque        (N.m) 612N.m / 1600rpm
Deutz F6L413F Net Dry Weight (kg) 605
Deutz F6L413F verall Dimension (mm) 1047×1038×860



Deutz BF6L913C Engine 141kw

Package



Deutz BF6L913C Engine 141kw
