Diesel Power Set

Fujian Saint Meilan Motor Wiring Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

SML

Model Number:

GF2

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name SML

Model Number GF2

Output Type AC Three Phase

Speed 1500RPM

Frequency 50HZ

Rated Power 20KW To 120KW

Rated Voltage 380V

Rated Current A

Specifications

diesel power set
1. Duetz engine, brushless alternator
2. 4 stroke, 3 phase, water cooled
3. 15 months warranty

diesel power set

1. Duetz engine, brushless alternator

2. 4 stroke, 3 phase, water cooled

3. 15 months warranty

Duetz Series Diesel Generator Sets
Genset Model	Rated Power		Standby Power		Fuel cons.	Engine Model	Bore×Stroke (mm)	Displacement (L)	Dimensions	weight
Genset Model	Kw	KVA	Kw	Kva	≤ g/Kw.h	Engine Model	Bore×Stroke (mm)	Displacement (L)	(L×W×H)mm	Kg
SML-W20	20	25	22	27.5	258.1	495D	95 × 115	3.26	1780×750×1150	820
SML-W24	24	30	26.4	33	258.4	K4100D	100 × 115	3.61	1780×750×1150	900
SML-W30	30	37.5	33	41.3	251.6	K4100D	100 × 115	3.61	1950×800×1190	980
SML-W40	40	50	44	55	232	K4100ZD	100 × 115	4.33	1950×850×1350	1050
SML-W50	50	62.5	55	68.8	220	R4105AZD	105 × 130	4.33	1950×850×1350	1080
SML-W60	60	75	66	83	224	R6105ZD	105 × 125	6.49	2450×900×1400	1230
SML-W70	70	87.5	77	96.3	224	R6105ZD	105 × 125	6.49	2450×900×1400	1460
SML-W80	80	100	88	110	218	R6105AZLD	105 × 130	6.49	2500×900×1400	1590
SML-W90	90	112.5	99	124	218	R6105AZLD	105 × 130	6.49	2500×900×1400	1640
SML-W100	100	125	110	138	218	R6105IZLD	105 × 135	6.49	2500×900×1400	1710
SML-W120	120	150	132	165	218	R6113ZLD	113 × 125	6.49	2600×900×1450	1790
