China Factory Auxiliary Type Diesel Generator 5 Kva
US$ 450 - 750
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
diesel generator
Model Number:
GF3-5kw
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
12kw Import Japan Yanmar Engine GeneratorUS$ 2,000 - 60,000MOQ: 1 Set -
Cheapest Chinese Electrical Generators Hand StartingUS$ 510 - 810MOQ: 1 Set
-
5kw Silent GeneratorUS$ 510 - 700MOQ: 2 Sets
-
Water-cooled Single Cylinder Portable Diesel Generator SetUS$ 600 - 2,500MOQ: 1 Set
-
Single Cylinder Diesel China Cheapest GeneratorUS$ 475 - 3,000MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
diesel generator
Model Number
GF3-5kw
Output Type
AC Single Phase
Speed
3000 3600rpm
Frequency
50hz/60hz
Rated Power
5kw
Rated Voltage
230V
Rated Current
17.2A
china factory auxiliary type diesel generator 5 kva
1. Rated power: 3kw , 5kw , 6kw
2. 178, 186 ,188 engine, air cooled , single /3-phase
3. brushless alterator with capacitor
| Air-cooled Diesel Generator Sets (Single Phase) | ||||||
| Model | SML3GF-LN | SML5GF-LN | SML6GF-LN | |||
| Rated frequency(Hz) | 50 | 60 | 50 | 60 | 50 | 60 |
| Rated voltage(v) | 110,120,220,230,240,220/110,240/120 | |||||
| rated output power(kw) | 2.8 | 3.3 | 4.2 | 5 | 5 | 5.5 |
| Max output power(kw) | 3 | 3.6 | 5 | 5.5 | 5.5 | 6 |
| Dc output | 12V-8.3A | |||||
| Power factor cos1 | 1 | |||||
| Phase number | Single-phase | |||||
| Fuel tank capacity (l) | 16 | |||||
| Continuour running time (hr)(at rated power) | 12.5 | 11.5 | 8.5 | 7.5 | 8.5 | 7.5 |
| Noise level{db(A)/7m}(zero load-full load) | 70-74 | |||||
| Overall dimension{mm}(LXWXH) | 825*520*740 | 910*520*740 | 935*520*715 | |||
| Packing dimension {mm}(lXWXH) | 855*550*780 | 950*550*780 | 960*550*770 | |||
| Net weight kg | 132 | 156 | 171 | |||
| Gross weight kg | 150 | 170 | 185 | |||
| starter system | electric starter | |||||
| Engine model | 178FGE | 186FGE | 186FAGE | |||
| Engine type | Single cylinder,4-stroke,air-cooled,vertical,diesel engine | |||||
| Bore*stroke(mm) | 78*62 | 86*70 | 86*72 | |||
| Displancement (cc) | 296 | 406 | 418 | |||
| Rated rotation speed (rpm) | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 |
diesel generator Warranty policy
Guarantee for one year or 1200 hours whichever reach first from ex-factory date ,During the guarantee period ,Saint will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material,After expiration ,"Saint "provides cose spare pars maintenance of gensets.
diesel generator Manufacturing standards
ISO9001 2008 ,CE ,GB/T2820,GB755 ,SONCAP ,AND SO ON.
