Specifications
Generating set1) UK technology,foton lovol engine
2) Stamford alternator
3) FG Wilson generator set
4) Low fuel consumpion
SALE !! 2013 brand new Lovol Open and silent type generating set
generator set Features
1) Engine and alternator shall be mounted on a same frame steel skid
2) Built-in damper for anti-vibration
3) Small size, low weight, easy to operate, installation and maintenance
4) World most famous brand diesel engine: UK FG Wilson series-1003G, 1004TG, 1006TG1A, 1006TG2A, 1006TAG
6) Advanced and reliable control module: Key start, auto start
7) Full range protects function and alarm shutdown feature
8) According to professional standards
Alternator features
1) Brush-less, 4 poles, rotation magnet
2) IP21-23 (NEMA1) enclosure is standard for all industrial alternators
3) The insulation system is class H
4) Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts
Standard accessories
Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires
Optional accessories
Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, control system with RS232/485, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer.
Type of Gensets | KVA | KW | Engine Specification | Dimension (mm) | Weight (kg) | Base tank(L) | ||||||
ESP | PRP | ESP | PRP | Engin type | Consump 100% Load(L/h) | Cylinder | Governor | Asp | ||||
GF3-16KW | 20 | 25 | 16 | 20 | 1003G | 6 | 4L | M | NA | 1450*650*1190 | 754 | 40 |
GF3- 20kw | 25 | 30 | 20 | 24 | 1003G | 6 | 4L | M | NA | 1450*650*1190 | 754 | 40 |
GF3- 24kw | 33 | 30 | 26 | 24 | 1003TG | 6 | 4L | M | NA | 1450*650*1190 | 754 | 40 |
GF3- 30kw | 42 | 38 | 33 | 30 | 1003TG | 7.5 | 4L | M | NA | 1450*650*1190 | 808 | 60 |
GF3- 34kw | 46 | 42 | 37 | 34 | 1004G | 9.5 | 4L | M | NA | 1600*620*1250 | 833 | 80 |
GF3- 48kw | 66 | 60 | 53 | 48 | 1004TG | 13.5 | 4L | M | TC | 1600*620*1140 | 867 | 100 |
GF3- 56kw | 77 | 70 | 62 | 56 | 1004TG | 14 | 4L | M | TC | 1600*620*1140 | 982 | 120 |
GF3- 68KW | 94 | 85 | 75 | 68 | 1006TG1A | 17 | 6L | M | TC | 1950*720*1190 | 1156 | 150 |
GF3- 80KW | 110 | 100 | 88 | 80 | 1006TG2A | 20 | 6L | M | TC | 2250*1150*2050 | 1248 | 150 |
GF3-110kw | 143 | 130 | 114 | 104 | 1006TAG | 28 | 6L | E | TCA | 2280*830*1460 | 1385 | 150 |
