XLPE Insulated Steel Wire Armour(SWA) Cable

Name: XLPE Insulated Steel Wire Armour(SWA) Cable
Brand: taifa
SKU: 129220153
Availability: InStock

US$ 1 - 999 MOQ: 1 Kilometer

Key Specifications

Place of Origin:

Henan, China

Brand Name:

taifa

Model Number:

YJV/YJLV, YJV22/YJLV22, YJV32/YJV32

Henan Taifa Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name taifa

Model Number YJV/YJLV, YJV22/YJLV22, YJV32/YJV32

Insulation Material XLPE

Type Medium Voltage

Application Industrial

Conductor Material Aluminum

Jacket PVC

XLPE INSULATED PVC SHEATH Steel Wire armoured Electric Cable

Standard: IEC60502

xlpe insulation power cable

The data sheets below show the most common standards,British standard and IEC standard.

Type		Description	Main Application
Cu core	Al core	Description	Main Application
(ZR)YJV or (ZR)YJY	(ZR)YJLV or (ZR)YJLY23	(Flame retardant) Cu, Al core XLPE insulated, PVC or PE sheathed power cable.	For laying indoor, tunnel, underground and canal. Unable to bear external mechanical pulling force and pressure during laid.
(ZR)YJV22 or (ZR)YJY23	(ZR)YJLV22 or (ZR)YJLV23	(Flame retardant) Cu, Al core XLPE insulated, steel armoured, PVC or PE sheathed power cable.	For laying indoor, tunnel, underground and canal. Able to bear external mechanical pulling force , but unable to bear large pulling force.
(ZR)YJLV32 or (ZR)YJLV33	(ZR)YJLV32 or (ZR)YJLV33	(Flame retardant) Cu, Al core XLPE insulated, fine steel wire armoured, PVC or PE sheathed power cable	For laying in shaft, water under ground and large difference of level, able to bear mechanical pressure and moderate pulling force.
(ZR)YJLV42 or (ZR)YJLV43	(ZR)YJLV42 or (ZR)YJLV43	(Flame retardant) Cu, Al core XLPE insulated, thick steel wire armoured, PVC or PE sheathed power cable	For laying in the water, seabed and large difference of level, able to bear large mechanical pressure and pulling force..
