Product Details
Place of Origin: | Henan, China | Brand Name: | taifa | Model Number: | power cable |
Insulation Material: | XLPE | Type: | Low Voltage | Application: | Construction |
Conductor Material: | Copper | Jacket: | PVC |
Product Description
Factory sale four core XMVK cable power xlpe copper cable
Specifications for XMVK/ymvkcables
YMvKmb Cable 0.6/1KV YMvKmb Flexible XMvK Cable 450/750V NEN Power & Control Cable
YmvK-mb Cable 600/1000V to IEC60502
XMVK unarmoured cable struction | |||||
Conductor section:2.5 mm2 Rated voltage:450/750v | |||||
Line core number and conductor nominal section | Norminal thinkness of insulation(mm) | Norminal thinkness of sheath (mm) | Overall Diameter (mm) | At 20 DC Resistance of conductor (Ω/km) | |
2x2.5 | 0.6 | 1.4 | 9.2±0.2 | 7.41 | |
3x2.5 | 0.6 | 1.4 | 9.6±0.2 | 7.41 | |
4x2.5 | 0.6 | 1.4 | 10.3±0.2 | 7.41 | |
5x2.5 | 0.6 | 1.4 | 11.5±0.3 | 7.41 |
YMvK is a series of very unique flexible installation cables. The cables are built as flexible installation cables by one of the world's leading cable producers. The cables are manufactured of PVC and it is suited for all use in street lights, industry and building installations. They are very suitable for installations where a flexible connection is needed such as in a motor, generator and similar.
UL3266 XLPE wire dimensions:
Conductor | Insulation | Max.Cond Resistance (Ω/KM) | Unit length (M)(Ft) | |||
Size (AWG) | Construction (No./mm) | Diameter (mm) | Nominal Thickness (mm) | Diameter (mm) | ||
32 | 7/0.08 | 0.24 | 0.39 | 1.02 | 563 | 610/2000 |
30 | 7/0.10 | 0.3 | 0.39 | 1.08 | 361 | 610/2000 |
28 | 7/0.127 | 0.38 | 0.39 | 1.16 | 227 | 610/2000 |
26 | 7/0.16 | 0.48 | 0.39 | 1.26 | 143 | 305/1000 |
24 | 11/0.16 | 0.6 | 0.39 | 1.38 | 89.3 | 305/1000 |
22 | 17/0.16 | 0.76 | 0.39 | 1.54 | 56.4 | 305/1000 |
20 | 21/0.18 | 0.94 | 0.39 | 1.72 | 35.2 | 305/1000 |
18 | 16/0.254 | 1.18 | 0.39 | 1.96 | 22.2 | 305/1000 |
16 | 26/0.254 | 1.5 | 0.39 | 2.28 | 14 | 305/1000 |
14 | 41/0.254 | 1.89 | 0.39 | 2.67 | 8.78 | 305/1000 |
12 | 65/0.254 | 2.37 | 0.39 | 3.15 | 5.53 | 305/1000 |
10 | 105/0.254 | 3.02 | 0.39 | 3.8 | 3.476 | 305/1000 |
Application | YMvKmb is Copper conductor, XLPE insulation, PVC sheath, NEN type power and control cable. Designed for energy supply in cable ducts, power stations, and industry and distribution boards and in subscriber networks. May also be used in brickwork and in concrete with the exception of cabling in shaken, vibrated or compressed concrete. Can be installed in open area, underground, in water and indoors where mechanical damages are not to be expected. | |
Standard | IEC 60502, K42C | |
Construction | Conductor : | Solid or Stranded bare copper (IEC 60228 Class 1 or Class 2)
|
Insulation : | XLPE (Code color HD 308) | |
Covering : | Taped or Extruded | |
Sheath : | PVC (Grey) | |
Technical Data | Working Voltage : | Uo/U = 0.6/1KV |
Test Voltage : | 4000V/5min No breakdown | |
Min. Bending Radius : | Single core 15×Ø , Multi core 12×Ø | |
Working Temperature : | Flexing -5°C to +90°C, Fixed -40°C to +90°C | |
Flame Retardant : | IEC 60332 | |
Cable Marking : | YMvKmb CABLE ***mm² 0.6/1KV SHSU |
Application | YMvKmb is bare Copper conductor, XLPE insulation, PVC sheath, NEN type power and control cable. Designed for energy supply in cable ducts, power stations, and industry and distribution boards and in subscriber networks. May also be used in brickwork and in concrete with the exception of cabling in shaken, vibrated or compressed concrete. Can be installed in open area, underground, in water and indoors where mechanical damages are not to be expected. | |
Standard | IEC 60502, K42C | |
Construction | Conductor : | Solid or Stranded bare copper (IEC 60228 Class 1 or Class 2)
|
Insulation : | XLPE (Code color HD 308) | |
Covering : | Taped or Extruded | |
Sheath : | PVC (Grey) | |
Technical Data | Working Voltage : | Uo/U = 0.6/1KV |
Test Voltage : | 4000V/5min No breakdown | |
Min. Bending Radius : | Single core 15×Ø , Multi core 12×Ø | |
Working Temperature : | Flexing -5°C to +90°C, Fixed -40°C to +90°C | |
Flame Retardant : | IEC 60332 | |
Cable Marking : | YMvKmb CABLE ***mm² 0.6/1KV SHSU |
