Best-selling Twisted Electric Wire Cable for House Hold RVS Cable
Specifications
Solid Power Cable,Twisted Electric WireHigh quality & competitive price.
Fast delivery & sincere service.
best-selling RVS Twisted Electric Wire cable for house hold
Solid/rigid and flexible/stranded types for choice
Product characteristic:
1. Product according to the state standard GB5023, JB8734.
2. After immersed in water for 1 hour, No puncture tested with A. C 50Hz250V(450/750V) 2000V(300/500V) for five minutes.
Using characteristic:
1. This product is suitable for the circuit of the power, appliance, instrument and meter or telecommunications equipment, . ., etc, which the rated A. C voltage is below 450/750V.
2. Long-term working temperature of the cable should not exceed 70, BV-90 type should not exceed 90.
3. The lay temperature of the wire should not less than 0, the allowed bending semidiameter for the out diameter which less than 25mm should not less than 4D, The out diameter which bigger than 25mm should not less than 6(D).
| Model/ Specifications |
Number and nom.cross-- section of conductors mm² |
Nominal Insulation thickness mm |
Mean overall dianmeter (upper limit mm) |
Max.D.C.resistance of copper conductor(20 Ω/km |
Min.insulation resistance(70MΩ.KM |
|
RVS2×28/0.15 |
2×0.5 |
0.5 |
6.0 |
39.0 |
0.012 |
|
RVS2×24/0.2 |
2×0.75 |
0.6 |
6.2 |
26.0 |
0.011 |
|
RVS2×32/0.2 |
2×1.0 |
0.6 |
7.0 |
19.5 |
0.010 |
|
RVS2×48/0.2 |
2×1.5 |
0.7 |
7.6 |
13.3 |
0.010 |
|
RVS2×49/0.25 |
2×2.5 |
0.8 |
8.2 |
7.98 |
0.009 |
|
RVS2×57/0.3 |
2×4.0 |
0.8 |
9.2 |
4.95 |
0.007 |
|
RVS2×85/0.3 |
2×6.0 |
0.8 |
10.3 |
3.39 |
0.006 |
Standard: ISO,CCC,ROHS
We have exported for more than 10years. and we can make a variety of specification power cables.
