CNC Router CX-6090
Techinical parameter
Applicable industry:
lAdvertising: billboard, logo,sign,3D characters cutting,acrylic cutting,LED/neon channel,literal-
hole cut,lightbox mold,stamp,mould,etc.
lDecoration: acrylic, density board, organic glass, soft metals like aluminum,etc.
1.Technology
Model |
CXG3030 |
|
Working Area |
300×300×80mm |
|
Spindle Motor |
2.2KW water-cooled spindle |
|
Working Mode |
Stepper motor |
|
Control System |
DSP(128MB) or PCIMC control system |
|
Drive Mechanism |
German imported ballscrew for x,y,z axis |
|
Table Surface |
T-slot with clamp |
|
Frame |
Cast aluminum |
|
Motion Positioning Accuracy |
± 0.05/300mm |
|
Repositioning Accuracy |
± 0.05mm |
|
Max Motion Speed |
9,000mm/min |
|
Max Engraving Speed |
5,000mm/min |
|
Rotating Speed of Spindle |
2,4000rpm |
|
Engraving Tools |
3.175mm, 4mm 6.00mm |
|
Dictate Formate |
G code, *.u00, *.mmg, *.plt/HPGL/NC |
|
Operating Voltage |
AC220/50Hz |
|
Software |
Type3 original with Dongle or Wentai , ArtCAM software/ARTCAM/CAXA |
|
Packing Size |
85×85×160mm |
|
Net Weight |
50kg |
|
Gross Weight |
95kg |
|
Optional Parts |
Dust Collecting System |
|
square guide rail | ||
Rotary Device | ||
oil mist | ||
servo | ||
DSP System w/Portable Control Pad (128MB) | ||
Features
1. Double nut ball screw,
2.Special dustproof structure and with long life
3.special mode of saving different points
Samples
our exhibition
Certiications:
Questions and answer:
Q1.how to get the most suitable machine and best price
please tell the material you want to working on ?
How to working on it ? Engraving ? Cutting ? Or other ?
What’s the MAX size of these material ?( length ? Width ? Thickness ?)
Q2: Do you have the manual of machine.
Yes,we have
Q3.If we donot know how to use the machine,can you teach us?
Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if you are busy ,we will have the special engineer to your country,but you need to bear some fee,like tickets and hotel and meal.
Q4.How about your after-sales service?
we offer you 24 hours service phone,skype or MSN.
Q5.How about your guarantee period?
one year and during the time,if you have any questions ,we will solve it for free.
Thank you for your any kind inquiry!!!
