Specifications
1.Japan yaskawa servo2.TAIWAN HIWIN Guide rail
3.Ce&ISO&SGS
Techinical parameter
Model |
M25 |
Working size |
1300*2500*200mm |
Body structure |
Steel structure |
Working table |
vacuum table with vacuum pump (option: T-slot&clamp table vacuum table, or vacuum and T-slot clamp table |
Working accuracy |
±0.05mm |
Repositioning accuracy |
±0.05mm |
Traveling speed |
50m/min |
Working speed |
25m/min |
spindle |
4.5 KW water cooling (option:HSD or Domestic best quality air cooled spindle) |
Spindle rotary speed |
0-24000rpm |
Spindle swiveling degree |
0~±90° |
Control system |
DSP(Option:Nc-studio (computer control) |
driver |
MIddle peed M860 Of Chinese best brand Option:High speed JIEMEIKANG 2260 or LEADSHINE2278 |
motor |
Stepper(option:Chinese servo ,and TAIWAN Delta servoor Japan Yaskawa servo and Panasonic servo) |
Transmission mode |
Taiwan TBI square guide rail for XYZ axis, gear wheel for XY axis, ball screw for Z axis(Option:round guide rail) |
Inverter: |
provide |
Collects&bits |
ER25(3.175/4/6/12.7mm. Optional ) |
Working voltage |
AC380V/50HZ or 60Hz/220v |
Max. power consumption(without spindle) |
1.84KW |
Command language |
G-code,*u00,*mmg,*plt |
Software |
Type3/Artcam/Ncstudio/Ucancam/JDpaint etc software |
Cutters |
10 pieces with diameter of 6 and 12.7 |
Collets |
2 pieces |
Running environment temperature |
0-45 centigrade |
Relative humidity |
30%-75% |
Mini order quantity |
1 set |
warranty |
1 year |
Machine weight |
1000kg |
Packaging Measure |
370cm*210cm*195cm |
Optional parts |
1.Air cooling spindle (HSD) or water cooling spindle 2.Taiwan Syntec or LNC system and Delta inverter 3.Japan Yaskawa/800w or Panasonic/750w servo motors 4.Vacuum pump(Germany Becker or chinese water and free oil pump) 5.Rotary system 6.Dust collector
|
Specifications
APPLICATIONS
Furniture:ideally suitable for processing cabinet door, wooden door, solid wood furniture, panel wood furniture, windows, tables and chairs, etc.
Other wooden products: stereo box, computer desk, musical instruments, etc.
Well-suited for processing panel, insulating materials, plastic, epoxy resin, carbon mixed compound, etc.
Decoration: acrylic, PVC, density board, stone, organic glass, soft metals like aluminum and copper, etc.
