Specifications
1.A professional factory with years experience2.Hiqh quality & reasonable price
3.Honest&loyal
4.Main Compotents Imported
PVC Window Fabrication Machinery:
PVC Profile Windows and Door Corner Cleaning Machine
1. Cleaning the up/bottom surface and the external corner.
2. Special cutter to clean the external corner.
3. Need change cutter to clean different kinds of profiles.
Main Specification and Technical Parameters:
Input Voltage: 220V/50Hz
Input Power: 1.1Kw
Milling Cutter Revolution: 2800r/min
Air Pressure: 0.5-0.8Mpa
Air Consumption: 15L/min
Profile Height: 25-90mm
Profile Width: 25-120mm
Overall Dimension: 1050*670*1370mm
Weight: 700kg
>>Related all PVC window machine models:
√ PVC window Cutting saw:
(SDS-350x3500)...................................Double mitre saw
(LJZ2-450x3700)..................................Double head cutting saw
(SVS-65).................................................V cutting saw
(SGB-1800)...........................................Glazing bead cutting saw
(SJVA-55)...............................................Window mullion Cutting Saw
(LJZ2-500X4200) ................................Double-head precision cutting saw
(LJZX-500X4200) ................................Double-head precision cutting saw with digital display
(LJZ2-CNC-500X4200) ......................CNC Double-head precision cutting saw
etc.
√ Welding machine:
SH01.................................................. Single head variable angle welding machine
SHZ2C...............................................Double-head welding machine
SHZ3C...............................................Three-head welding machine
SHZ4C...............................................Four-head welding machine
SHP4-3000....................................... Four corner vertical welding machine
SHP4A-CNC-3000...........................CNC four corner vertical welding machine
SHP4W-CNC-3000..........................CNC four corner horizontal welding machine
etc.
√ Milling machine:
LZFA-300x100..................................Automatic lock-hole milling machine
LXF-290x90.......................................Single head copy-routing machine
LXF2-300x100................ .................Double head copy-routing milling machine
SCX02-2 ..........................................Double-spindle water slot milling machine
SCX02-3 ..........................................Three-spindle water slot milling machine
SCX02-4........................................... Four-spindle water slot milling machine
LXD-200........................................... Ending milling machine
SXD-80.............................................. End milling machine
LXD3-250 ..........................................Heavy duty end milling machine
SXF-18x20......................................... Cap-seal milling machine for PVC profile
etc.
√ Cleaning machine:
SQJ01-120......................................... Corner cleaning machine
SQJ04-CNC-120.............................. CNC corner cleaning machine
SQJA-CNC-120.................................CNC corner cleaning machine
SQJ05-120.........................................V corner cleaning machine
√ Others:
SHQX-CNC-3000...............................Automatic corner welding and cleaning production line
SJG01...................................................Automatic screwdriver machine
SYH01-1800........................................Profile bending machine
etc.
>> Aftersales Service:
Warranty for a whole year; Maintenance for lifetime; technical support; installing and debugging; stuff training, etc.
>> Please do not hesitate to contact us for your business booming!
>> Any enquiries are warmly welcomed.
>> We'll give you an immediately respond to your enquiry!
♥ Please do not hesitate to contact us for your order! ♥
