aluminum profile Multi-head drilling machine for aluminum windows & curtain wall aluminum profile drilling LZZ6-13

Specifications

1. Multi-head aluminum drilling machine for aluminum windows & curtain wall aluminum drilling LZZ6-13
2.ISO9001,Sncee 1991









Multi-head drilling machine for aluminum windows & curtain wall aluminum profile drilling LZZ6-13





1. Multi-head drilling machine for aluminum windows & curtain wall aluminum profile drilling LZZ6-13
2.IS0-9001-2008 /CE



Equipment  Features:



1. Used for drilling holes on aluminum profiles and curtain wall profiles, expecially apply for long workpieces and mass production.

2. The processing Max. profile section size is 250*250mm, and the max. processing length is 5000mm.

3. Multi-head boring anchor can be fixed to meet multi-holes processing requirement.

4. Feeding system adopts hydraulic-damping cylinder, which ensures a smooth feeding.

5. Imported PLC control system makes a possible machine heads' linkage.



Main Specification and Technical Parameters:



Mode	LZZ6-13
Power Supply	380V 50Hz
Cutting Motor Power	4*0.75kw
Max Drilling Hole Diameter	13mm
Max. Distance Between Two Drilling Holes	5000mm
Min. Distance Between Each Group Holes	300mm
Power Unit Quantity	4
Max. Moving Distance at Horizontal Direction of Drilling Head	120mm
Moving Distance at Vertical Direction	150mm
Worktable Size (L*W)	300*220mm
Drilling Head Feeding Travel	125mm
Feeding Pressure	0.5~0.8MPa
Max. Processing Profile Section Size	250*250mm
Overall Dimension(L*W*H)	5500*1100*1800mm
Weight	about 880kg

Quality Guarantee:





 The Seller shall provide all spare parts needed, be responsible for spare parts replacement  and TWELVE(12) months guarantee.



After guarantee period all costs of replacement, cost of spare parts, shipment cost, and others cost shall be covered by Buyer.





Technical service:



The seller will supply free online technical service, free training program for the buyer’s staff , on-site installation.
