It is outer adheres on the bottom of the fuel tank and no need directly to contact with the fuel level that could be real-time detection the height of fuel level. It could be widely used in various types of vehicles for fuel measuring and monitoring, also could be combined with GPS/GPRS communication technology, through the computer software management platform to achieve scientific management vehicles, prevent fuel theft behavior and save the vehicle operating cost.
Features:
1) Measuring precision; 2) Good stability; 3) Easy installation; 4) Simple application;
5) Strong antistatic ability (EMC); 6) With standardization data interface; 7) Alarm output;
Usage:
1) Fuel level measurement of various kinds of vehicles (for current fuel capacity, refuel, fuel consumption and anti-theft fuel);
2) In industrial: Measuring liquid displacement, thickness, distance, liquid level, material level …it is suitable for measuring the level of medium, liquid gas medium height measurement;
Technical parameters:
Operating Voltage |
DC9V-36V |
|
The power supply ripple |
Less than 100mV |
|
Operating current |
Less than 55mA |
|
Measuring distance |
3cm to 100cm; pressure-bearing range: -0.1MPa~32MPa |
|
Resolution |
0.1mm |
|
Measurement accuracy |
0.5% |
|
Temperature compensation range |
-40 °C- +80 °C |
|
Output mode: | ||
Analog output |
Voltage output (default) |
1-5V (corresponding 0-100cm) |
|
Current output (optional) |
4-20mA (corresponding 0-100cm) |
|
Digital output |
RS232(default) |
See the “communication protocol” |
RS485(optional) | ||
Anti-theft alarm output |
need external connection a alarming horn to achieve alarm |
|
Install method |
bottom of fuel tank/can, water tank |
|
Operating temperature |
-40 °C - +80 °C |
|
Storage temperature |
-50 °C - +100 °C |
|
Size |
102*48*25mm (with mounting holes) |
|
Ultrasonic transducer | ||
Operating temperature |
-40 °C - +80 °C |
|
IP grade |
IP66 |
|
Cable length |
8m, with shield |
|
Gross weight(G) |
About 770g |
|
