It could be widely used in the oil monitoring of all kinds of vehicles, also could be combined with the communication technology of GPS/GPRS and via computer software management platform to achieve scientific management of vehicle and then to prevent oil theft and be saving the vehicle operating cost.
Features:
1) Measuring precision, measurement resolution is 0.1mm, liquid level measurement accuracy is 0.5%.
2) Good stability; 3) Easy to install; 4) Simple application; 5) Strong antistatic ability (EMC);
6) Variety of standard signal output ways, which are analog voltage (1-5V) and current (4-20mA), digital output RS232 and RS485; 7) Alarm output;
Technical parameters:
Operating Voltage |
DC9V-36V |
|
The power supply ripple |
Less than 100mV |
|
Operating current |
Less than 55mA |
|
Measuring distance |
4cm to 100cm; pressure-bearing range: -0.1MPa~32MPa |
|
Resolution |
0.1mm |
|
Measurement accuracy |
0.5% |
|
Temperature compensation range |
-40 °C- +80 °C |
|
Output mode: | ||
Analog output |
Voltage output (default) |
1-5V (corresponding 0-100cm) |
|
Current output (optional) |
4-20mA (corresponding 0-100cm) |
|
Digital output |
RS232(default) |
See the “communication protocol” |
RS485(optional) | ||
Anti-theft alarm output |
need external connection a alarming horn to achieve alarm |
|
Install method |
bottom of fuel tank/can, water tank |
|
Operating temperature |
-40 °C - +80 °C |
|
Storage temperature |
-50 °C - +100 °C |
|
